RADIAL DRILLING MACHINE

Name: RADIAL DRILLING MACHINE
Brand: Eagle
SKU: 140924760
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Eagle

Eagle Industries, Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name Eagle

Model Number DR 800A~DR 1300

CNC or Not Normal

Certification CE

Specifications

RADIAL DRILLING MACHINE
With wide range of speed and feed, with manual,power and fine feeds

RADIAL DRILLING MACHINE

1.With wide range of speed and feed,with manual,power and fine feeds.The feed of machines are very easily engaged and disengaged at any time.

2. With safe and reliable feed safety machine,all parts easy operation and change.

3. Main parts are made by machine center which import form KIA with high precision and efficiency,ensuring reliability and high quality.

4. Integrating technology for casting parts is excellent,adopting casting equipment, ensuring high quality of materia for basic parts.

5. Spindle parts are made by special high quality steel heat treatment which made by first class equipments,ensuring high strength and durability.

6. Main gears are machining by gear grinding,ensuring high precision and low noise.

Model	Unit	DR 800A		DR 1000		DR 1000A		DR 1300
Max.Drilling capacity	mm	32	40	32	40	32	40	40
Distance spindle axis to column generating line	mm	320~820		200~1000		300~1000		300~1000
Diameter of column	mm	200		240		240		250
Spindle taper		MT4		MT4		MT4		MT4
Spindle travel	mm	240		250		280		280
Spindle speeds range	r/min	75~1220		71~1800		32~2500		78~1250
Spindle speeds series		6		8		16		6
Range of Spindle feeds	mm	0.1~0.25		0.13~0.54		0.1~1.25		0.1~0.32
Spindle feeds	mm	3		4		8		3
Max.Distance spindle nose to working surface of base	mm	120~860		264~1064		220~1000		260~1200
Dimension of worktable	mm	400×400×350		400×450×400		600×450×450		600×410×450
Dimension of base	mm	1370×700×160		1500×740×160		1710×800×160		1855×860×160
Overall Size	mm	1407×720×1885		1730×750×2360		1760×800×2050		1860×870×2340
Power of Main motor	kw	1.5		2.2	3	2.2	2.2	3
G.W/N.W	kg	1425/1200		1700/1400		2100/1600		2500/2100
Packing dimension	mm	1550×770×2100		1870×970×2200				1900×1000×2300
Item NO.		146030	146035	146040	146045	146050	146055	146060
