HIGH SPEED SMALL HOLE EDM DRILLING MACHINE
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Place of Origin
Shandong, China
Brand Name
Eagle
Model Number
EDM
Certification
CE
Specifications
HIGH SPEED SMALL HOLE EDM DRILLING MACHINEEDM Machine
1.The speed of drilling hole is 30mm-60mm depth per minuter(it is different for different material)
2.Can drill small holes on the various conductive materials,especially stainless steel,chilled steel,copper,aluminium and hard alloy etc.
3.Z axis with fixing function
4.Can dill deep hole with diameters 0.3mm-3mm(thedepth-diameter ratio is 300:1)
5.Can dill wire-cut starting hole,filter hole,jet hole,gas hole,group holes and hole of super depth etc.
6.Can drill on oblique and curved surface directly.
7.Can easily erode the drill and screw tap ect which is broken in the workplace and not destroy the screw thread of the holes.
| Model | EDM30×40 | EDM30A×40 |
| Dimension of working table (mm) | 400×600 | 400×600 |
| Travel of working table (mm) | 300×400 | 300×400 |
| Z axis travel (mm) | 350 | 350 |
| W axis travel (mm) | 300 | 300 |
| Max.distance director to work table (mm) | 100-400 | 100-400 |
| Max.machining current (A) | 30 | 30 |
| Electrode diameter (mm) | Φ 0.3-Φ 3.0 | Φ 0.3- Φ 3.0 |
| Load of table (kg) | 200 | 200 |
| Working liquid | Water | Water |
| Power supply | 380V/50HZ | 380V/50HZ |
| Max.power consumption | 3.5 | 3.5 |
| Machine dimensions (mm) | 1000×970×1800 | 1000×970×1800 |
| Machine weight (kg) | 800 | 800 |
| Digital display | Two-axis digital display(optional three-axis digital display) | Two-axis digital display(optional three-axis digital display) |
| Function of turning | No | Yes |
| Item NO. | 161052 | 161053 |
