J41 TAPPING CHUCK
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Eagle
Model Number:
J41
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shandong, China
Brand Name
Eagle
Model Number
J41
Specifications
This device is most applicable to tap working on drill, lathe, boring machine, milling machine and CNC machine center and so on.J41 TAPPING CHUCK
This device is consisted of a tap chuck and tap collets. The chuck has compensating device for thread pitch.Collet chuck has overload torque protection device, which avoid tap breaking. In order to get the different release torques for different diameter taps.just adjust mnts. This device is most applicable to tap working on drill, lathe, boring machine, milling machine and CNC machine center and so on.
| Item NO. | Shank taper | D(mm) | d(mm) | L1(mm) | L(mm) | Tapping range | Torque Nm | Weigt(kg) |
| 576302 | R8 | 46 | 19 | 101.6 | 193.6 | M3~M16 | 46.3 | 1.71 |
| 576304 | MS2 | 46 | 19 | 75 | 171.5 | M3~M12 | 25 | 1.08 |
| 576306 | MS2 | M3~M16 | 46.3 | |||||
| 576310 | MS3 | 46 | 19 | 94 | 191 | M3~M12 | 25 | 1.28 |
| 576314 | MS3 | M3~M16 | 46.3 | 1.61 | ||||
| 576316 | MS3 | 66 | 30 | 227 | M12~M24 | 150 | 3.2 | |
| 576318 | MS4 | 46 | 19 | 117.5 | 216 | M3~M12 | 25 | 3 |
| 576322 | MS4 | M3~M16 | 46.3 | |||||
| 576324 | MS4 | 66 | 30 | 252 | M12~M24 | 150 | 3.6 | |
| 576326 | MS5 | 66 | 30 | 149.5 | 284 | M12~M24 | 150 | 4.5 |
