GS 4080 PRECISION SURFACE GRINDER

GS 4080 PRECISION SURFACE GRINDER thumbnail-1
GS 4080 PRECISION SURFACE GRINDER photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
Used
Type:
Other, Precision Surface Grinder
CNC or Not:
Normal
Contact Supplier Request Quote Chat Now
Eagle Industries, Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition Used
Type Other, Precision Surface Grinder
CNC or Not Normal
Place of Origin Shandong, China
Brand Name eagle
Model Number GS 4080 PRECISION SURFACE GRINDER

Specifications

GS 4080 PRECISION SURFACE GRINDER

GS 4080 PRECISION SURFACE GRINDER






Model   GS 2050A GS 2550A GS 3063A GS 30100A GS 4080A
GS 2050B GS 2550B GS 3063B GS 30100B GS 4080B
GS 2050C GS 2550C GS 3063C GS 30100C GS 4080C
Table size (W*L) mm 200×460 250×500 305×635 305×1020 406×813
Table travel (X*Y) mm 510×238 560×275 765×340 1130×340 910×450
Max.distance from spindle center to table surface  mm 450 450 580 580 580
Magnetic chuck size mm 200×460 250×500 300×600 300×1000 400×800
Longitudinal moving speed of worktable m/ 7~25 7~25 7~25 7~25 7~25
min
Table transverse movement Auto feed mm/ 0.1-8 0.1~8 0.1~8 0.1~8 0.1~8
min
Rapid speed m/ 990 990 990 990 990
min
Feed of handwheel mm/ 0.02 0.02 0.02 0.02 0.02
div
Wheelhead vertica movement Auto feed mm/ (C)0.005/0.01/ (C)0.005/0.01/ (C)0.005/0.01/ (C)0.005/0.01/ (C)0.005/0.01/
min 0.02/0.03/ 0.02/0.03/ 0.02/0.03/ 0.02/0.03/ 0.02/0.03/
  0.04/0.05 0.04/0.05 0.04/0.05 0.04/0.05 0.04/0.05
Rapid speed mm/  (B)460   (C)240  (B)460 (C)240  (B)460   (C)240  (B)460 (C)240  (B)460   (C)240
min
Feed of handwheel mm/ 0.005 0.005 0.005 0.005 0.005
div
Gringding wheel speed rpm 2850(50HZ) 2850(50HZ) 1450(50HZ) 1450(50HZ) 1450(50HZ)
3450(60HZ) 3450(60HZ) 1750(60HZ) 1750(60HZ) 1750(60HZ)
size (OD×W×ID) mm 200×20×31.75 200×20×31.75 350×40×127 350×40×127 350×40×127
Spindle Motor kw 1.5 2.2 5.5 5.5 5.5
Hydranlic motor kw 0.75 0.75 2.2 2.2 2.2
Cooling pump motor kw 0.04 0.04 0.125 0.125 0.125
Elevating motor kw (B)0.25 C)0.5 (B)0.25 (C)0.5 (B)0.25 (C)0.5 (B)0.25 (C)0.5 (B)0.25 (C)0.5
Cross feed motor kw 0.04 0.04 0.04 0.04 0.04
Max.loading capacity of table kg 120 180 270 270 270
Total rated power kw 3 3.7 9 9 9
Height of machine mm 1675 1675 1890 1890 1890
Floor space (L×W) mm 2050×1400 2300×1600 2800×2200 4400×2200 3600×2400
Gross weight kg 1600 1800 2800 2500 3800
Package dimensions (L×W×H) mm (200/A)1780×1500×2155 (200B/200C)1906×1716×2195 (250/A)2116×2016×2208 2350×2220×2150 2950×2220×2210 2850×2270×2180
(250B/C)2316×2016×2208
Item NO.   121101 121111 121121 121131 121141
121102 121112 121122 121132 121142
121103 121113 121123 121133 121143







Explain
GS A mean:auto feed on transverse,hydrawlic transmisson on longitudinal,manual on vertical.
GS B mean:auto feed on transverse,hydrawlic transmisson on longitudinal,rapid movement on vertical.
GS C mean:auto feed on transverse,hydrawlic transmisson on longitudinal,auto feed on vertical.
Standard accessory
Wheel flange and special tools Wrench for hexagonsocket head screw
Balance arbor Wheel
Wheel levelling wedge and screw Coolant tank
Wheel dresser base Adjustable wrench(200)
Tool box Screw driver
Wheel extractor
Optional
Wheel Balance stand
Dust collector
Dust and coolant euqippment
Coolant system with magnetic separator
Paper Filter
Magnetic Paper Filter
Parallel Dresser
Wheel Chuck
Electro magnetic chuck
