aeration diffuser for water treatment
- SHANGHAI
- T/T
You May Like
-
aeration tank for waste water treatment
-
aeration machine for waste water treatment
-
Fine bubble disc diffuser for waste water treatment
-
Bubble disc diffuser for waste water treatment
-
Fine disc bubble membrane diffuser for waste water treatment
-
Tube bubble membrane diffuser for water treatment for environment
Product Details
| Brand Name | DCH | Model Number | aeration pipe |
Product Description
Specifications
aeration diffuser1.import or China mater
2.long life
3.lower cost
aeration diffuser parameter
Membrane material:EPDM/silicone
Lining Pipe material:ABS/UPVC/PP
Item | 67mmx500mm | 67mmx750mm | 67mmx1000mm |
Oxygen transform efficiency(%) | >30 | >30 | >30 |
Working air flow(m3/h) | 1-5 | 1-7 | 1-12 |
Designed air flow(m3/h) | 3 | 5 | 7 |
Service area(m2/piece) | 0.45-1 | 0.5-1.2 | 0.75-1.5 |
Hole number(pc) | 8080 | 12300 | 16880 |
Bubble dia(mm) | 1-3 | 1-3 | 1-3 |
Drag loss(pa) | <3000 | <3000 | <3000 |
Oxygenate capability(kgO2/h) | 0.45 | 0.55 | 0.65 |
Theoraetic dynamic efficiency(kgO2/kw.h) | 6.5 | 7 | 7.5 |
aeration diffuser technical parameter
Item | 75mmx500mm | 75mmx750mm | 75mmx1000mm |
Oxygen transform efficiency(%) | >30 | >30 | >30 |
Working air flow(m3/h) | 2-7 | 3-8 | 4-12 |
Designed air flow(m3/h) | 5 | 7 | 10 |
Service area(m2/piece) | 0.75-1.5 | 1-1.8 | 1.5-2.5 |
Hole number(pc) | 8650 | 12500 | 17400 |
Bubble dia(mm) | 1-3 | 1-3 | 1-3 |
Drag loss(pa) | <3000 | <3000 | <3000 |
Oxygenate capability(kgO2/h) | 0.55 | 0.75 | 1.0 |
Theoraetic dynamic efficiency(kgO2/kw.h) | 7 | 7.5 | 8 |
aeration diffuser technical parameter
90mmx750mm | 90mmx1000mm | ||
Oxygen transform efficiency(%) | >30 | >30 | >30 |
Working air flow(m3/h) | 4-10 | 5-12 | 6-18 |
Designed air flow(m3/h) | 6 | 8 | 12 |
Service area(m2/piece) | 0.9-1.8 | 1.25-2.5 | 1.75-3 |
Hole number(pc) | 9620 | 15175 | 19400 |
Bubble dia(mm) | 1-3 | 1-3 | 1-3 |
Drag loss(pa) | <3000 | <3000 | <3000 |
Oxygenate capability(kgO2/h) | 0.65 | 0.85 | 1.25 |
Theoraetic dynamic efficiency(kgO2/kw.h) | 7.25 | 8 | 8.5 |
aeration diffuser technical parameter
Item | Φ110m*500mm | Φ110mm*750mm | Φ110m*1000mm |
Oxygen transform efficiency(%) | >30 | >30 | >30 |
Working air flow(m3/h) | 6-12 | 9-18 | 12-24 |
Designed air flow(m3/h) | 7 | 10 | 15 |
Service area(m2/piece) | 1.15-2.25 | 2.28-4.75 | 6-8.85 |
Hole number(pc) | 14300 | 20400 | 28600 |
Bubble dia(mm) | 1-3 | 1-3 | 1-3 |
Drag loss(pa) | <3000 | <3000 | <3000 |
Oxygenate capability(kgO2/h) | 0.85 | 1.10 | 1.55 |
Theoraetic dynamic efficiency(kgO2/kw.h) | 7.5 | 8.5 | 9 |
aeration diffuser diffuser finally
aeration diffuser for water treatment
aeration diffuser company information
aeration diffuser company FQA
