3kW DC to AC Inverter for Telecom

Name: 3kW DC to AC Inverter for Telecom
Brand: Dorik
SKU: 140913518
Availability: InStock

Ningbo DORIK Import & Export Co., Ltd.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Dorik

Model Number:

DR-48V-3kw

Payment & Shipping

Payment Methods:

Port of Shipment:

any china port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Dorik

Model Number DR-48V-3kw

Input Voltage Other, DC 48V

Output Voltage AC220V±0.5%

Output Frequency 50HZ±0.05%

3kW DC to AC inverter for telecom

We are professional and creative manufacturer. Our reliable quality of rectifiers will definitely satisfy your requirements.

Advantage:

1) Small, light and high efficiency

2) High frequency pulse current output

3) Flexible use, simple operation

4) Complete protection function

Product Overviews

Product Parameters

Model No	DR-48V-3KW
Power	3kw
Output Voltage	AC220V±0.5%
Output Waveform	pure sine wave
Output Frequency	50HZ±0.05%
DC Input Voltage	48V
Transient Recovery Time	<5mS
Voltage Distortion (Liner load )	THD<1%
Voltage Distortion (Non-liner load)	THD<3%
Power Factor	0.8(Lag)
Frequency Tracking Range	50Hz±3Hz(±1Hz, ±2Hz adjustable)
Frequency Precision (battery invert)	±0.05%
Inverter Overload Ability	110% 60mins; 125% 10min; 150% 60s
Load Peak Ratio	3:1
Whole-set Work-Efficiency	Up to 94%(invert efficiency >97%)
MTBF	≥ 100000 hour
Size(mm)	482×420×178
Weight (kg)	28
