Specifications
1) Small size2) Silent as vertical wind driven generator
3) Simple installation
4) The invertor is power efficiency, and si
Specifications
1. Variable pitch
2. On-grid system
3. Maintenance free
4. High efficiency
We are the manufacture of wind generator and we have the power 100w -10kw.which model you want you can contact me and I will try my best to satisfy your demand as possible.
Features
1. Starting with low speed; high wind energy utilization; beautiful appearance; low vibration on operation.
2. Being installed by human design and easy for installation, maintenance and repair.
3. Being molded through precise injection with new process, together with the optimized design of
aerodynamic contour and structure, our wind turbine blades have such advantages: high utilization of
wind energy which contributes to the annual energy output.
4. Our generators, adopting patented permanent magnet rotor alternator, with a special kind of stator
design, efficiently decrease resistance torque of the generators. Meanwhile, it makes the wind turbines
match the generators quite well and increase the reliability of their operation.
100w wind generator tech data
Model | NE-100S | NE-200S |
Rated power | 100W | 200W |
Maximun power | 130W | 230w |
Rated voltage | 12/24V | 12/24v |
Start-up wind turbine | 2.0m/s | 2.5m/s |
Rated wind speed | 10m/s | 11.5m/s |
Survival wind turbine | 55m/s | 55m/s |
Top net weight | 6.0kg | 6.5kg |
Wheel diameter | 1.2m | 1.3/1.4m |
Number of blades | 3/5 | |
Blades material | Nylon fiber | |
generator | Three phase permanent magnet ac synchronous generator | |
magnet | NdFeB | |
Generator case | Casting aluminum alloy | |
Control system | Electromagnet/wind wheel yaw | |
Speed regulation | Automatically adjust windward direction | |
Working temperature | -40°C - 80°C | |
Design life | 20 y | |
Gross weight | 8kg | |
Package Dimension | 670*280*190mm | |
