1000W Vertical Wind Generator

US$ 500 - 600 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Type:

Wind Power Generator

Jining Bafang Mining Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Type Wind Power Generator

Specifications

Specifications
1. Variable pitch
2. On-grid system
3. Maintenance free
4. High efficiency

Specifications

1,windmill generator
2,net weight 15kg,high wind energy utilization
4,low vibration operation
5,low resistance

Features

1. Starting with low speed; high wind energy utilization; beautiful appearance; low vibration on operation.

2. Being installed by human design and easy for installation, maintenance and repair.

3. Being molded through precise injection with new process, together with the optimized design of

aerodynamic contour and structure, our wind turbine blades have such advantages: high utilization of

wind energy which contributes to the annual energy output.

4. Our generators, adopting patented permanent magnet rotor alternator, with a special kind of stator

design, efficiently decrease resistance torque of the generators. Meanwhile, it makes the wind turbines

match the generators quite well and increase the reliability of their operation.

Specification

Model	NE-1000
Rated power	1000W
Maximun power	1500W
Rated voltage	48V
Start-up wind turbine	3m/s
Rated wind speed	10m/s
Survival wind turbine	45m/s
Top net weight	37kg
Wheel diameter	2.8m
Number of blades	3
Blades material	Nylon fiber/ reinforced glass fiber
generator	Three phase permanent magnet ac synchronous generator
magnet	NdFeB
Generator case	Casting aluminum alloy
Control system	Electromagnet/wind wheel yaw
Speed regulation	Tail furling
Working temperature	-40°C - 80°C
Design life	20 y
