Relay AC Contactor Relay intermediate relay
- 100000000 Piece / Pieces per Month
- Qingdao port
- D/P D/A Credit Card
-
The PFSA103D 3BSE002492R0001 motor controller offers a high degree of reliability
-
Acrel Distribution transformer protection measurement and control device AM5SE-T 4-20mA analog output
-
Acrel Motor differential protection AM5SE-MD measuring and controlling device is applied to high power asynchronous motor
-
Acrel Bus-link protection and self-input measurement AM5SE-B and control device bus charging modbus over ethernet
-
Acrel smart motor protector ARD2M K125 series protect timeout start-up overload unbalance short circuit
-
Acrel smart motor protector ARD2M K125 series protect timeout start-up overload unbalance short circuit
Product Details
| Place of Origin: | Shandong, China | Brand Name: | Bafang | Model Number: | Models |
| Theory: | Electromagnetic Relay | Usage: | General Purpose | Size: | Miniature |
| Protect Feature: | Sealed | Contact Load: | Low Power |
Product Description
Relay AC Contactor Relay intermediate relay
Product Details | |||
Brand Name | Shaman | Item No. | JZ7-44 |
Color | Black | MOQ | 100 pcs |
Packing | 60 PCS in one carton. | ||
Important Information | |||
Send sample | Yes | ||
Delivery time | Within 30 days. | ||
Payment terms | T/T 30% deposit, the balance before the shipment. | ||
Introduction:
AC Contactor Relay is mainly used for AC 50Hz (can be used after derived 60Hz), rated working voltage up to 380V or 220V DC rated voltage to the control circuit to control a variety of electromagnetic coils, so that the signal or signals at the same time expanding passed to the con-trol elements.
Specification: 24V 36V 110V 220V 380V
JZ7 Relay Construction Features:
- Relay structure: open type, air electromagnetic type. Shell made of heat fixation plastic, and moving organizations use directly operated type.
- Auxiliary contact use double breakpoint and bridge structure.
- Installation: screw tightening.
Main technical parameters:
Relay contact combinations have three types:
Model | JZ7-44 | JZ7-62 | JZ7-80 |
Number of normally opened contacts | 4 | 6 | 8 |
Number of normally closed contacts | 4 | 2 | 0 |
The voltages of coil operating attracted by relays:
AC 50Hz,12,24,36,110,127,220,380V
The basic parameters of the relay
Rated isolation voltage UiV | Convention althermal current | The rated current under the different rated voltage | capacity control | |||||
Making
| Breaking | |||||||
690 | 5 | AC-15 | ||||||
120V | 127V | 220V | 240V | 380V | 3600VA | 360VA | ||
3 | 2.83 | 1.64 | 1.5 | 0.95 | ||||
DC-13 | ||||||||
110V | 125V | 220V | / | / | ||||
