Miniature Intermediate Power General Purpose Relay

Jining Bafang Mining Machinery Co., Ltd.
Miniature Intermediate Power General Purpose Relay thumbnail-1
Miniature Intermediate Power General Purpose Relay thumbnail-2
Miniature Intermediate Power General Purpose Relay thumbnail-3
Miniature Intermediate Power General Purpose Relay thumbnail-4
Miniature Intermediate Power General Purpose Relay photo-1
Miniature Intermediate Power General Purpose Relay photo-2
Miniature Intermediate Power General Purpose Relay photo-3
Miniature Intermediate Power General Purpose Relay photo-4
US$ 3 - 4 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Bafang
Model Number:
Models
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Bafang
Model Number Models
Theory Solid State Relay
Usage General Purpose
Size Miniature
Protect Feature Sealed
Contact Load High Power

  Miniature Intermediate Power General Purpose Relay

Product Details

Brand Name

Shaman

Item No.

JZ7-44

Color

Black

MOQ

100 pcs

Packing

60 PCS in one carton.

Important Information

Send sample

Yes

Delivery time

Within 30 days.

Payment terms

T/T 30% deposit, the balance before the shipment.



Introduction:

AC Contactor Relay is mainly used for AC 50Hz (can be used after derived 60Hz), rated working voltage up to 380V or 220V DC rated voltage to the control circuit to control a variety of electromagnetic coils, so that the signal or signals at the same time expanding passed to the con-trol elements.

Specification: 24V 36V 110V 220V 380V

JZ7 Relay Construction Features:

  • Relay structure: open type, air electromagnetic type. Shell made of heat fixation plastic, and moving organizations use directly operated type.
  • Auxiliary contact use double breakpoint and bridge structure.
  • Installation: screw tightening.

Main technical parameters:

Relay contact combinations have three types:

Model

JZ7-44

JZ7-62

JZ7-80

Number of normally opened contacts

4

6

8

Number of normally closed contacts

4

2

0



The voltages of coil operating attracted by relays:

AC 50Hz,12,24,36,110,127,220,380V

The basic parameters of the relay

Rated isolation voltage UiV

Convention althermal current

The rated current under the different rated voltage

capacity control



Making



Breaking

690

5

AC-15

120V

127V

220V

240V

380V

3600VA

360VA

3

2.83

1.64

1.5

0.95



DC-13



110V

125V

220V

/

/
