Home > Industrial Equipment & Components > Filtration Equipment & Parts > Machine Oil Purifier > Pall Series Hydraulic Oil Filter Housing

Pall Series Hydraulic Oil Filter Housing

Name: Pall Series Hydraulic Oil Filter Housing
Brand: Lefilter
SKU: 140909264
Availability: InStock

Xinxiang Lifeierte Filter Corp.,ltd

Pall Series Hydraulic Oil Filter Housing thumbnail-1

Pall Series Hydraulic Oil Filter Housing thumbnail-2

Pall Series Hydraulic Oil Filter Housing photo-1

Pall Series Hydraulic Oil Filter Housing photo-2

US$ 150 - 350 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

Lefilter

Place of Origin:

China

Model Number:

HCP100A38050KC

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin or qingdao

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name Lefilter

Place of Origin China

Model Number HCP100A38050KC

Certification yes

After-sales Service Provided Engineers available to service machinery overseas

Usage Other, air Compressor

Condition New

Brief introduction

PEC oil filtration cart adopts new green filtration components .On many occasions it filters solid
particles in many kinds of liquid in effectively.

Product unique characters:
1.Locking differential pressure alarm and prevent the false alarm when cold start.

2.Filter strainer with by-pass valve to avoid system fluid off.

3.Motor lack phase or misphase protection

4.Acousto-optic differential pressure alarm prompt replace filter element

arse filter to protect pump in suction oil mouth.

6.Oil outlet diffuser to prevent air from oil tank

7.Universal wheel makes cart flexible and convenient

8.Increase the oil collecting tray and tubing fixed installation

9.Oil pump with overflow valve

Technical data

Model	PFC8924 -25	PFC8314 -50	PFC8314 -100	PFC8314 -100	PFC8314 -150	PFC8300 -50-YV	PFC8300 -100-YV	PFC8314 -400
Rated pressure (Mpa)	1.0 MPa
Motor power (Kw)	0.75kw	1.5kw	3kw	3kw	4kw	2.2kw	4kw	15kw
Power	380V×3P/50Hz
Rated flow rate(L/min)	25	50	100	100	150	50	100	400
Filtration precision	ß×=1000(×=2.5,5,7,12,22)/old standard ß×≥200(x=1,3,6,12,25um)
Working temperature(°C)	0~80°C
Media	Mineral oil,water glycol,phosphate ester flame resistant fluid

PFC 8924-25-*2 *1

Filter element model:

HC9404F *1 13 *2

*1:

Filter element
Filter material	Precision(ßx≥1000)
KZ	2.5(1)
KP	5(3)
KN	7(6)
KS	12(12)
KT	22(25)

*2:

Seal
NO.	Sealing material	Liquid media
H	NBR	Petroleum base oil,oil -in- water emulsion,water glycol
Z	VITON	phosphate ester flame resistant fluid

Filter model:

PFC 8314-*1 *4 *2 *6

PFC 8314U-100-*4 *2 *6 *

Filter element

HC8314F-*1 *4 *2 *6

Filter Rmodel:

PFC 8300-*1 *4 *2 *6

Filter element model:

HC8300 E-*5 *3 *4
*1

NO.	Flow rate(L/min)	Note
50	50
100	100
150	150	Only used for PFC8314
400	400	Only used for PFC8314

Our products through the following test:
ISO 2941 Collapse & Burst Resistant
ISO 2942 Material Compatibility with Fluids
ISO 2943 Material Compatibility with Fluids
ISO 3724 Flow Fatigue Characteristics
ISO 3968 Pressure Drop vs. Flow Rate
ISO 16889 Multi-pass Performance Testing

Why choose us?
1. Manufacturer, the best price for you...
2. OEM is accpted. We can manufacture the products according to your requirement.
3. Free samples. We are honored to offer you samples, you just need to pay the freight.
4. Quality Guarantee: Our products are tested and checked one by one before shipment.
5. Short delivery time: 2--10 working days (based on the quantity)
6. First-class service:
         Technical advisory for any time.
         Answer all your questions about the products patiently .
         Provide you newest goods transport conditions until you receive the products.
         If any quality problem , we will supply you the new replaced ones.
