Engine Peak Indicators ( Peak Pressure Gauges)
Negotiable
MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
All-K Marine
Model Number:
with handle
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
All-K Marine
Model Number
with handle
Specifications
Engine Peak IndicatorsIMPA:652631-652632
For easy and quick measurement of the maximum peak pressure of engines.
Engine Peak Indicators
IMPA:652631-652632
For easy and quick measurement of the maximum peak pressure of engines.
nsists of three major components: a check valve, a preesure guage and exhaust valve. The maximum peak pressure is directly read on the dial when the indication has settled. There is no need for diagram acquisition, area measurement with a planimeter, or length measuremrent with a scale. Oil-filled pressure guages are uesd as indicators to provide ouutstanding viibration-resisitant characteristics. The internal pressure is released to zero by opening the exhaust valve after measurement.
| Code | Pressure Range(kgf/cm²) | Minimum Graduation(kgf/cm²) | Accuracy | Dial Size mm | Mterial of Bourdon Tube |
| 652631 | 0-100 | 5 | ±1.5%FS | 60 | SUS-316 |
| 652632 | 0-150 | 5 | ±1.5%FS | 60 | SUS-316 |
