Help CenterPreset Type Torque Wrenches
Related Products
Specifications
Torque Wrenches1.IMPA:611426-611433
2.Model:Preset type
3.Application:suitable for high effciency mass production
Torque Wrenches
IMPA CODE: 611426-611433
1. Suitable for high efficiency mass production.
2. By presetting the wrench you cantighten bolts to a desied torque every time.
3. To operate, you first pull the handle until it clicks to the set position.
4. Then you thighten the bolt until the resistance of the wrench stops.
5. When you release the wrench, it is automatically set for the next operation.
6. No need to refer to a dial or meter during use allowing you to increse work speed substantially.
7. For use with a socket wrench.
| Code | Capacity min.-max. N.m-cm | Scale N.m-cm | Sq.Drive | Overall L mm | Weight kgs |
|
611426 27 28 29 30 |
2-6 4-12 5-25 10-50 20-100 |
0.1 0.2 0.25 0.5 1.0 |
6.3 6.3 9.5 9.5 12.7 |
175 185 220 250 330 |
0.12 0.18 0.23 0.43 0.67 |
|
611431 32 33 |
40-200 40-280 60-420 |
2.0 2.0 2.0 |
12.7 19.0 19.0 |
475 675 975 |
1.40 1.80 3.20 |
