20mm diameter CNC hydraulic bar straightening machine
- 5960 Piece / Pieces per Month
- Qingdao port
- T/T Credit Card
- GT-TZ14B Straightening Machine
- Low/Middle/High Carbon Steel Straightening Machine Steel Wire Drawing Machine for Drawing Wire
- Low/Middle/High Carbon Steel Straightening Machine Steel Wire Drawing Machine for Drawing Wire
- Coil Feed Laser Blanking Line
- Decoiler Straightener
- Precision Pressfeed Stamping Line
Product Details
Condition: | New | Type: | Other, Straightener & Cutter | Use: | Bar |
Place of Origin: | Shandong, China | Brand Name: | qk | Model Number: | GT8-12 |
Voltage: | 220V/380V | Power(W): | 6kw | Dimension(L*W*H): | 1520x550x1380mm |
Weight: | 460kg | Certification: | ISO9001 | Warranty: | 1 Year |
After-sales Service Provided: | No overseas service provided |
Product Description
Related Products
Specification
Model | GT8-12 | GT12-20 |
Dimensions | 1520x550x1380mm | 2050x600x1570mm |
Guide rail | 3m | 3m |
Total power | 6kw | 7kw |
Cutting length error | <1mm | <1mm |
The longest cut length | 3m-6m | 3m-6m |
The length of the shortest cut | 7cm | 7cm |
Material rack specification | 30x30 Square steel milling | 35x35 Square steel milling |
Weight | 460kg | 820kg |
Straightening speed | 12—26m/min | 12-26 m/min |
Rebar size | 6—12mm | 10—20mm |
Number of straightening wheel | 8pcs | 8pcs |
Discharge chute width | 14mm | 22mm |
Detail
Advantage
1. Zero error
2. Double speed straightening feed
3. The modulation wheel straightening,It does not hurt reinforced,the straightness accuracy is high
4. Using alloy steel circular arc cutting tool, the approximate circle cut surface
5. The rack adopts a whole steel milling a durable, wire walking process card material
6. The machine runs smoothly, firm and durable
7. For the long screw rod and the wall wire processing and construction site
Packing & Shippment
Company Information
Jining Qingke Machinery Co., Ltd established in July 29, 2015, registered capital of 5 million.
This is our new branch. Our factory has 6 years history. We have CNC machining center, CNC
lathe, boring machine, and milling machine.
Main products: CNC hydraulic bar straightener, Bending machines, Straightening machines, Steel arc bending machine, Ground polishing machines, Terrazzo machines, Solar water pump, Garden Machinery(including tree spade & lawn mower), Construction machinery and accessories, Road marking and Mining equipment, Mining tools and so on.
We have passed the ISO9001:2000 certification. Our products have been exported to Europe, Russia, south America, Africa & the Middle East, more than 20 countries. We sincerely hope to have the opportunity to co-operate with you.
