Specifications
Diesel high pressure Water Pumps:1. one year warranty
2.Easy maintenance
3.Used for irrigation and horticulture
Introduction:
* Powered by air cooled 4-stroke diesel engine
* Aluminum alloy high pressure easing
* High quality and mechanical sealed equipment
* Compact structure ,light weight,easy operation
* Easy
Kama Diesel Engine
1) Type: 1-cylinder, 4-stroke, air-cooled swirl chamber diesel engine
2) Work capacity: 296CC
3) Max. Output: 7horsepower/3000rpm
4) Ignition system: Non-contact transistor
5) Starting system: Recoil
6) Fuel tank capacity: 3.5L
7) Continuous operating time: 3hours
8) Engine oil system capacity: 1.1L
Diesel engine advantage:
1.Competivite price and best quality
2.New design and good market
Water Pump:
1) Diameter of outlet/inlet: 2inch
2) Max. Delivery lift:55
2) Rated power:4kw
3) Max. Water displacement: 500L /MIN
Size and weight:
1) Over dimension(L*W*H): 605*450*560mm
2) Dry weight:44
| Model | YL-DHP50 |
| Suction port diameter | 2" |
| Discharge port diameter | 2" |
| Suction Head | 8m |
| Total Head | 55m |
| Flow Rate | 500L/min |
| Start Method | Recoil/Electric start |
| Fuel Tank capacity | 3.5L |
| Engine Model | YL178F |
| Type | single-cylinder ,Vertical,air-cooled ,4-stroke,Direct Injection |
| Engine speed | 3600rpm |
| Rated output | 4kw |
| BorexStroke | 78x62mm |
| Displacement | 296cc |
| Lube-oil Capacity | 1.1L |
| Net weight | 44kgs |
| Dimension | 605x450x560mm |
Diesel engine drwaing and pump curve
FAQ
1.Q: What is your MOQ of this item?
A: 5-10PCS
2.Q: What is the lead time?
A: 25-30 days after receiving your L/C or TT deposit.
3.Q: Is it all right to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Ningbo, China Port.
5.Q: What are your payment terms?
A: 30% deposit and balance T/T against copy of Bill of Lading or L/C at sight.
6.Q: What is your company's available production capacity?
A: 3000-5000 pieces against your orders.
Canton fair & exhibition of our company
