YL-DWP80A Diesel water pump (3 inch) Diesel water pump (3 inch) diesel water pump price manual water pump kama water pump
small diesel engine water pump. competivite price and good market
1.170F(4.5HP) match / 168F(3.5hp) diesel engine accept
ntuninues working: 4hours
3.Fuel consumption:310-320G/KW.H
4.flow rate:600L/min
5.lift(m) 21
6.suction(m) 5
7.displacement:208cc
8.20’GP=330pcs, 40’HQ=750pcs
Water Pump Type: self-priming pump
outlet size(inch)/(mm) 3"/80
inlet size(inch)/(mm) 3"/80
flow rate:600L/min
lift(m) 21
suction(m) 5
Engine Model:170F (4.5hp)
start mode Recoil
fuel 0#(summer);-10#or-20#(winter) diesel
fuel tank capacity 3L
Lube-oil capacity:0.7L
Packing Dimensions(mm) 510x378x410
Net Weight(kg) 29
| Engine specifiaction | single cylinder,4-stroke,swirl chamber,forcible air cool diesel engine |
| suction port diameter | 80mm |
| Discharge port diameter | 80 mm |
| Maximum capacity | 40 m3/h |
| suction height | 5 m |
| lift height | 21 m |
| self priming time | 120 s/4m |
| water pump type | self -priming |
| Displacement (cc): | 208cc |
| Bore X Stroke (mm): | 70x54mm |
| Rate Out put power | 4.5 HP |
| Fuel Tank Capacity (L): | 3 L |
| start system | recoil start |
| Rotation dirction | anti-clockwise |
| fuel type | 0# in summer . 10# in winter diesel oil |
| lube tank capacity (L) | 0.7 L |
| lube type | above SAE10W30 cc grade. |
| demension ( LxWxH) | 510x378x410 |
| Net weight (kg) | 29 kg |
Pump curve and drawing
