Specifications
High pressure water pump, diesel waterSelf-priming, vertival, Kama engine, direct injection
Irrigation water pump
High pressure water pump, diesel water pump
Usage:
1. Agriculture Irrigation water pump, water transportation
2. Urban city underground water draining, sewage pump,
3. Aquaculture draining and input water, water pump price
4. Seawater pump for fishing, pumping machine
5. Fire fighter fire-extinguishing. High pressure water pump
| Mode | YL-DHP50, high pressure water pump | |||||
| Suction Port Diameter | 2" | |||||
| Discharge Port Diameter | 2" | |||||
| Suction Head | 8m | |||||
| Total Head | 55m | |||||
| Flow Rate | 500L/min | |||||
| Start Mode | Electric Start | |||||
| Fuel Tank Capacity | 3.5 | |||||
| Net Weight | 46Kg | |||||
| Dimensions | 580*490*560mm | |||||
| Engine Mode | YL178F | |||||
| Type | Single-cylinder,Vertical,4-Stroke,Direct Injection,Air-cooled | |||||
| Engine Speed | 3600rpm | |||||
| Rated Output | 4.0KW | |||||
| Bore*Stroke | 78*62mm | |||||
| Displacement | 296cc | |||||
| Lube-oil Capacity | 1.1L | |||||
Why us?
1. We are factory, can provide product with competitive price and great quality
2. We save you time. U never need to find someone else in rush space when your product is in need. You can keep our offer and tell me your demands whenever you like
3. We save you money. Beside product, our ship agent provide very good ship freight and service
4. After sale service support. We guarentee our product quality, and provide problem accessory 1 year for free. Thought the problem is a seldom case.
5. Customerized design and service. We support your sale and offer your needs as tailored
6. Product range, we have five ranges of related produce, including Tiller, Water pump,Generator,Power sprayer and Engines. U never worry to gather different model for same container. We can provide satisfying product instead.
7. 10pcs above can be sent as trial order for sample test. 7 days sample delivery time
Production line, diesel water pump, irrigation water pump, farming pump.
| Model | YL178F | |||||
| Type | Single-cylinder,Vertical,4-Stroke,Direct Injection,Air-cooled | |||||
| Crankshaft Direction | Clockwise from flywheel end | |||||
| Cooling Type | Force air-cooled | |||||
| Lubrication type | Pressure splash | |||||
| Start Mode | Recoil/Electric Start | |||||
| Engine Speed | 3600rpm | |||||
| Consumption rate of fuel | ≤280g/Kw.h | |||||
| Consumption rate of machine oil | ≤4.08g/Kw.h | |||||
| Rated Output | 4.0KW | |||||
| Bore*Stroke | 78*62mm | |||||
| Compression ration | 20 | |||||
| Displacement | 296cc | |||||
| Fuel Tank Capacity | 3.5L | |||||
| Lube-oil Capacity | 1.1L | |||||
| Net Weight | 33Kg | |||||
| Dimensions | 383*421*445mm | |||||
Other Related water pump:
1.Diesel water pump, normal pressure, 2inch, 3inch, 4inc
2.Kerosene water pump, 2inch, 3inch
3.Gasoline water pump, forged steel pump set & hand chamber, 2inch, 3inch
3.Diesel water pump, Honda engine, 2inch, 3inc
4.Gasoline high pressure watr pump or diesel high pressure water pump, 1.5inch 2inch
5.Sea water pump, 2inch, 3inch
Water pump parts, water pump spare part:
CE Certificate, water pump set.
