Specifications
ATS LCD silent diesel genset1. Low noise 68dB
2. Easy operation & maintenance for diesel fuel
3. LCD digital screen
Why us?
1. We are factory, can provide product with competitive price and great quality
2. We save you time. U never need to find someone else in rush space when your product is in need. You can keep our offer and tell me your demands whenever you like
3. We save you money. Beside product, our ship agent provide very good ship freight and service
4. After sale service support. We guarentee our product quality, and provide problem accessory 1 year for free. Thought the problem is a seldom case.
5. Customerized design and service. We support your sale and offer your needs as tailored
6. Product range, we have five ranges of related produce, including Tiller, Water pump,Generator,Power sprayer and Engines. U never worry to gather different model for same container. We can provide satisfying product instead.
7. 10pcs above can be sent as trial order for sample test. 7 days sample delivery time
Features and benefits
a) Powered by Yongli 4-Stroke OHV diesel Engine.
b) Large muffler for quiet operation.
c) Standard configuration of voltmeter.
d) Neat and economical for classical design.
e) Circuit breaker protects overload operation.
f) Emergency low oil alert warn the low lube oil level.
g) AVR alternator provides stable voltage and current.
All engines are made by ourselves. We have ten years experience of making generators
YLD7700
| Model | YL-D7700LES | ||||
| AC Voltage | 220V,230V,240V,220/240V | ||||
| Power Factor | 1.0 | ||||
| Frequency | 50HZ | 60HZ | |||
| Rated Power | 5.5KW | 6.0KW | |||
| Start Mode | Electric Start | ||||
| Fuel Tank Capacity | 16L | ||||
| Continuous Operating Hours | 8h | ||||
| Noise Level 7m | 72dB | ||||
| Net Weight | 162Kg | ||||
| Dimensions | 955*560*745mm | ||||
| Engine Mode | YL188F | ||||
| Type | Single-cylinder,Vertical,4-Stroke,Direct Injection,Air-cooled | ||||
| Engine Speed | 3000rpm | 3600rmp | |||
| Rated Output | 6.8KW | 7.5KW | |||
| Bore*Stroke | 88*75mm | ||||
| Displacement | 456cc | ||||
| Consumption rate of fuel | ≤280g/Kw.h | ||||
| lube-oil Capacity | 1.65L | ||||
LCD Panel
Normal Panel:
ATS:
-------------------------------------------------------------------------------------------------------------------------------------------------------------------
| Model | KAMA YL188F | |||||
| Type | Single-cylinder,Vertical,4-Stroke,Direct Injection,Air-cooled | |||||
| Crankshaft Direction | Clockwise from flywheel end | |||||
| Cooling Type | Force air-cooled | |||||
| Lubrication type | Pressure splash | |||||
| Start Mode | Recoil/Electric Start | |||||
| Engine Speed | 3600rpm | |||||
| Consumption rate of fuel | ≤280g/Kw.h | |||||
| Consumption rate of machine oil | ≤4.08g/Kw.h | |||||
| Rated Output | 7.5KW | |||||
| Bore*Stroke | 88*75mm | |||||
| Compression ration | 19 | |||||
| Displacement | 456cc | |||||
| Fuel Tank Capacity | 5.5L | |||||
| Lube-oil Capacity | 1.65L | |||||
| Net Weight | 55Kg | |||||
| Dimensions | 485*485*545mm | |||||
------------------------------------------------------------------------------------------------------------------------------------------------
CE Certificate:
