5kw Diesel Generator (New Type) With Kama Engine

Name: 5kw Diesel Generator (New Type) With Kama Engine
Brand: YOLEE
SKU: 140880540
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

YOLEE

Model Number:

YL-DW6500

Zhejiang Yongli Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name YOLEE

Model Number YL-DW6500

Output Type AC Three Phase

Speed 3000rpm/min

Frequency 50HZ

Rated Power 5kw

Rated Voltage 220v

Rated Current 22A

Specifications

Diesel generator
1. CE approved, powered by advanced air-cooled diesel engine.
2. Noise-reducing enclosure, made of high-e

Model	YL-DW6500
Rated frequency (Hz)	50	60
Rated voltage (V)	220, 230, 240, 220/110, 230/115, 240/120

Rated output power (KVA)	4.5	4.5
Rated rotation speed (rpm)	3000	3600
DC output	12V, 7A
Power factor cosφ	1
Phase number	three phase
Excitation mode	Self-excitation Brushless

Noise level dB(A)@ 7m (zero load - full load)	70-74

Overall dimension [mm(in)](L× W× H)	920× 520× 700
	36.22× 20.47× 27.56
Net weight [kg(lbs)]	140 (308)
Structure model	Low noise type with enclosure
Connection mode	Single bearing, rotor drive shaft, rigid coupling
Engine model	186FE
Engine type	1-cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacement [cm³ (Cu-in)]	406 (24.78)
Compression ratio	19: 01
Rated power [KW(Hp)/rpm]	6.3 (8.6)/3600
Starting system	Electric starting
Rotation direction (view from flywheel)	Clockwise
Fuel type	0 (sumber), 10 (winter) diesel oil
Lube	SAE10W30 (above CC grade)
Low oil pressure alarm system	With
