Wood Crusher
Equipment introduction:
Wood chipping machine can chip kinds of round logs, branch, wood staff, square blocks into 10-30mm wood chips, the final wood chips can be used for burning as fuel, also can be used for making wood pellets after grinding into fine powder sawdust.
Wood chipper is our specially designed, operation is very easy and highly working efficiency
The machine is made up of high strength steel plate so it is strong enough for working. The knives are connected to the rotor by clamping plate. Connected by hydraulic system, the upper faced roller assembly can float up and down over the material to be cut within certain range according to the thickness of the material.
Technical parameters:
model |
450 |
550 |
650 |
750 |
850 |
950 |
1050 |
cutter diameter(mm) |
400 |
500 |
600 |
700 |
800 |
900 |
1000 |
quantity of blad |
4 |
4 |
4 |
6 |
6 |
4-6 |
4-6 |
length of blade(mm) |
100 |
130 |
150 |
200 |
230 |
260 |
300 |
inlet diameter(mm) |
160*170 |
200*200 |
250*250 |
300*300 |
350*350 |
400*400 |
450*450 |
speed of main shaft (mim/h) |
2600 |
2600 |
2300 |
2300 |
1500 |
1500 |
1500 |
motor (kw) |
5.5-7.5 |
11 |
15 |
18.5-22 |
30 |
37 |
45 |
diesel engine |
12-15 |
20 |
30 |
45 |
50 |
55 |
65 |
capacity (kg/h) |
600 |
800 |
1000 |
1500 |
2000 |
3000 |
4000 |
