Specifications
elastic arm vibrating screenFeed size: <150
screen size: 3mm
handling capacity: 30-80t/h
SYZD-32 elastic arm vibrating screen
Introductions:
1, use:
SYZD-32 vibrating screen is a new type of elastic arm of screening equipment, it is widely used in mining, coal, electric power, metallurgy, building material, refractory and so on all walks of life to big, small granular material in the material and graded homework.
2, characteristic:
SYZD-32 vibrating screen play arm series vibrating screen installation, the incline Angle between 20 ° to 35 °, compared with other same type product has the following features:
(1) the dip Angle is large, small volume, screening ability.
(2) light weight, easy installation and process arrangement.
(3) less energy consumption, can save a lot of energy.
(4) the price is low, quantity of spare parts.
(5) simple structure, beautiful shape.
(6) mesh sieving efficiency is about 20% higher than normal screen, with self-cleaning function.
(7) the sieve is dedicated to the blast furnace trough, the secondary screening
parameters:
model |
SYZD-32 |
cover surface |
1.62m*m |
leaning angle of screen |
28 degree |
Feed size |
<150 |
screen size |
3mm |
handling capacity |
30-80t/h |
Semi-oscillation |
16hz |
double-amplitude |
5±0.5 |
Motor model |
YZO-17-4 |
Motor power |
2*750w |
voltage |
380v |
Contact person: Nancy
Tel: +86-0371-86055113
Skype: nancymachine2008
QQ: 2696501824
Tm:cn1001881078
Send Inquiry to This Supplier
