Specifications
Mine heavy vibrating screenhandling capacity: 10-100
amplitude: 16
double-amplitude: 6-9
SYZD-50 Mine heavy vibrating screen
Introductions:
mine heavy vibrating screen is developed by our company is a new and efficient screening equipment, mainly used in metallurgy, mining, coal, building materials, electric power, chemical and other industries, especially in the metallurgical industry USES the most widespread, is under the blast furnace trough, coking plant, concentrator commonly used screening machine, the machine USES new energy-saving vibration motor or vibrator as vibration source, rubber spring support and vibration isolation, screen mesh has a large capacity, high screening efficiency, easy to change, and the advantages of easy installation and maintenance.
heavy vibrating screen is used for mine vibration motor or ordinary outside drag or natural vibration source drive, makes the screen body along the direction of vibration force for periodic reciprocating vibration, material direction along a straight line on the screen as a parabola, so as to achieve screening purpose.
mining heavy vibrating screen by the vibration source, screen body, screen, vibration damping device and bottom towing, sieve machine side panel is made of high qualified steel plate, side plate and beam, vibration bottom adopts high strength bolt connection or ring groove rivet, reasonable structure, strong and durable.
parameters:
model |
SYZD-50 |
screen area |
0.9m*m |
leaning angle of screen |
10 |
Feed size |
<150 |
screen size |
3 5 10 15 20 25 50 |
handling capacity |
10-100 |
16 |
|
double-amplitude |
6-9 |
Motor model |
YZO-10-6 |
Motor power |
2*1.0kw |
voltage |
380kg |
