brick/block molding machine
- 50 Set / Sets per Month
- qingdao/ningbo/gaungzhou
- T/T Credit Card
- China pe200x300 smallest jaw crusher
- Popular compound pendulum jaw crusher price
- 2016 china products stone coated steel roofing tile ,shingle steel roof tile
- 2016 china products lightweight roof tile,blue glazed roof tile
- colored metal roofing prices,sand coated metal roofing tiles
- roofing tiles coated with stones,roofing tiles for houses
Product Details
Condition: | New | Type: | Paving Block Making Machine | Brick Raw Material: | Cement |
Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
Capacity: | 8000-12000pcs/8h, Pavement block: 8000-12000pcs/8h | Place of Origin: | Henan, China | Brand Name: | SAIYE |
Model Number: | SYQT3-35 block molding machine | Voltage: | 380v | Power: | 16kw |
Dimension(L*W*H): | 4000*3500*2300mm | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
brick/block molding machineThe machine is suitable for processing the pavement flower block , square flower block , cement .
Multi-functional hydraulic pavement brick machine
The hydraulic pavement brick machine is the least machine for brick processing by
absorbing the advanced foreign technology . The machine is suitable for processing
the pavement flower block , square flower block , cement standard block , hollow
block and so on by changing the mold . The machine is droved by the hydraulic
system , two times feeding material (Concrete surface and color surface).
The machine has the advantages of small volume , powerful vibration ,
easy operation and maintenance stable working performance and so on ,
which is the advanced , economic and new type brick machine .
Technical parameter:
model | SYQT3-35 |
Forming account | Pavement block : 10pcs hollow block: 3pcs standard block: 20pcs perforated brick: 10pcs |
Forming time | 20-30/S |
Capacity | Pavement block: 8000-12000pcs/8h hollow block: 4500-6000pcs/8h standard block: 25000-28000pcs/8h |
vibrational frequency | 4500times/min ---5100times/min |
magnetic force | About 22kn |
Vibrational power | Y132S1-2 N=6KW |
Pallet size | 680*530*20mm |
oil pump | Q=40ML/r p=10mpa |
Up oil cylinder | 80*300 diameter: 32 |
Edge oil cylinder | 63*250 diameter: 32 |
Max Pressure of Hydraulic System | 6.3mpa |
Vibration power | 22KN |
Machine power | 16kw |
Weight | 4.8T |
Dimension | 4000*3500*2300mm |
Theory output
Model | name | Size of block | Pcs/pallet | pcs/8h |
QT3-35 | Block | 390*190*190 | 3 | 4500-6000pcs |
Hollow Brick | 200*100*60 | 10 | 8000-12000pcs | |
Standard Brick | 240*115*53 | 20 | 25000-28000pcs |
