Micro gringding machine
Brief introduction:
This machine consists of main engine, auxiliary engine, electric cabinet of three parts, with air separation type, screen, mesh free, uniform size and other performance, continuous production process.And reach the international advanced level, are widely used in material crushing in pharmaceutical, chemical and food industries.
Material by a hopper through screw conveyor into the crushing chamber, high-speed rotating blade shearing crushing, the material by using the method of negative pressure air shipment transported into the cyclone separator and bag filter and discharge material to achieve the requirement of the product.
The main technical parameters:
model |
Production capacity |
Feed particle size |
The discharging granularity |
power |
Spindle speed |
Overall dimensions |
weight |
SY-15 |
10-200kg/h |
<10mm |
80-320mesh |
13.5kw |
6000rpm |
4200*1200*2700mm |
850kg |
SY-30 |
30-800kg/h |
<15mm |
80-320mesh |
46kw |
3800rpm |
6640*1300*3960mm |
1500kg |
SY-60 |
50-1200kg/h |
<15mm |
80-320mesh |
84.15kw |
2800rpm |
7500*2300*4530mm |
3200kg |
