SYJ series micro pulverizer
This series of micro pulverizer, consists of main engine, auxiliary engine, electric control of three parts, compact design, reasonable structure, with air separation type, the advantages of no sieve net, inside the machine is equipped with classifiers, crushing, grading once completed.Negative pressure conveying the crushing operation timing cavity heat continuously, so is suitable for crushing of thermal sensitive material.The machine to adapt to the range, continuous production process, discharging granularity is adjustable.
Can handle such as:
chemical products, food, medicine, cosmetics, dyestuff, resin, shell material and other material crushing and classification.
Technical parameters:
Model |
SYJ-15 |
SYJ-18 |
SYJ-36 |
Capacity(kg/h) |
10-200 |
20-450 |
60-1000 |
Feed particle size(mm) |
<10 |
<12 |
<15 |
The discharging granularity(mm) |
80-320 |
80-450 |
80-450 |
Total power(kw) |
13.7 |
19.07 |
38.85 |
The speed(r/min) |
4500 |
4480 |
4000 |
Dimension(mm) |
5410*1660*2500 |
5500*1800*3100 |
9000*2200*4000 |
