SYZS series vibration sieve
Performance:
This machine consists of hopper, vibration chamber and coupling and motor.Oscillation indoor there are eccentric wheel, rubber software, main shaft, bearing, etc.Adjustable eccentric hammer driven by motor is transmitted to the main shaft centerline, under the unbalanced state, generate centrifugal force, to change the material forced vortex in orbit, the amplitude of heavy hammer regulator can be adjusted according to different materials and mesh size.The machine has compact structure, small volume, no dust, low noise, high output, low energy consumption, mobile, easy maintenance.
Technical parameters:
Model |
SYZS-350 |
SYZS-515 |
SYZS-650 |
SYZS-800 |
SYZS-1000 |
SYZS-1500 |
Capacity (kg/h) |
60-500 |
60-1300 |
180-2000 |
200-2500 |
300-3500 |
350-4500 |
Sieving mesh(mm) |
12-200 |
12-200 |
12-200 |
5-325 |
5-325 |
5-325 |
Motor power(kw) |
0.55 |
0.75 |
1.5 |
1.5 |
1.5 |
2 |
dimension(mm)(length*width*height) |
540*540*1060 |
710*710*1290 |
880*880*1350 |
900*900*1200 |
1100*1100*1200 |
1600*1600*1200 |
