SYG series Primary crusher
Brief introduction:
The machine is suitable for pharmaceutical, chemical, metallurgy, food, architecture, etc.Of strong and difficult pieces of material processing, including to crush plastic, copper, etc, also can be used as supporting equipment before fine crushing process.
This machine is a horizontal crushing mechanism, not affected by material viscosity and hardness.The limitation of softness and so on, can have better crushing effect for any material.Material is fed into the crushing chamber, by the impact of the blade and sword, rotating and stationary knife cut pieces at the same time, due to the effect of rotating centrifugal force, the material flows to the exit automatically.
The main technical parameters:
model |
Production capacity |
Feed particle size |
Grinding fineness |
Spindle speed |
The motor |
Overall dimensions |
Weight |
SYG-120 |
100-500kg/h |
Or less100mm |
0.5-20mm |
400r/min |
3kw |
700*800*1100mm |
250kg |
SYG-200 |
300-1000kg/h |
Or less100mm |
0.5-20mm |
400r/min |
5.5kw |
880*900*1250mm |
500kg |
