2L/min mist cooling fog system for Industrial, agricultural and horticultural Humidification

2L/min mist cooling fog system for Industrial, agricultural and horticultural Humidification

Feature:

1.Water Flow Rate: 2L/min;

2.Working Pressure: 80bar/1160psi;
3.Ceramic plunger Italy seal NSK bearing stainless steel cover,SS cover can avoid rust efficiently;

4.Stop working automatically when lack of water;
5.Fog can spray at different frenquency controlled by the digital timer.

6.Pump Type: Axial Pump(2plungers);
7.Power: 220V/50HZ(60HZ) or 110V/60HZ(50HZ) ; single phase(can do different voltage and rate);
8.Pump Motor Power: 300W;

9.Tubing Size: 3/8" (9.52mm);

10.Droplet size:  < 7μm;

11.Accessories List: 30m hose, 30 nozzles and 30 pcs connectors .







The way of supply water :
1.Using Tap water ;
2.Using Water tank ;



NOTE
When you using water tank :
Fog pump don't have the water absoption functions , when you need to using the water tank , please
buy a booster pump too , in order to keep the machine functions well .







Our products show:

Accessories for fog machine:

Meanwhile except for the Fog Pump ,we also supply all kinds of accessories, such as mist nozzles, connectors, hose and hose cutter.

Fog Pump : 0.2L , 0.3L , 0.5L, 1L, 2L , 3L, 4L, 7L , 11L, 15.4L

Fog Nozzle:
Thread size: 10/24" / 3/16" / 12/24" / 1/8"
Orifice size: 0.08mm/ 0.1mm/ 0.15mm/0.2mm/0.3mm,,,0.8mm
Material : Brass/ Brass coated with nickel / SS

Nozzle Connectors:
Threaded type material : Brass / Brass coated with nickel
Quick coupling type material: Brass coated with nickel
Thread size with fog nozzle: 10/24" / 3/16" / 12/24" / 1/8"

High pressure misting / fog pipe:
Pipe Size: 3/8" (9.52mm)
Material: PE or Nylon

1.Cooling

Residential cooling, outdoor cooling, commercial place cooling;

2.Humidification

Industrial, agricultural and horticultural: green house, garden, livestock farming;

3.Dedusting and Deodorization

Industry process, bulk powder, cement plant, foundry dust, fly ash control, waste transfer, recycling process;

4.Insect Control

Using water-soluble chemical to kill insect.

Why the customer like to choose us?
Our Advantages:

1.You are getting 100% factory price!!
   we have cooperated factory in Dongguan which have hundreds machines and 400 workers,100% OEM.

2.We can customize for you,and goods can be your brand as your requirements.

3.We have strong sales team,have a very quick reply within 6hours.
   and our sales person have big pentence and strong responsibility to customers.

4.We accept samples order,small quantity samples we can send you for free.

Your Questions:

1.How to order & How to Pay?
You contact us let me know which product you want to buy,then we make contract for you,after you comfirmed the contract , you pay it , then we arrange to send out the goods within the valid delivery time.

2.How Long & How to delivery?
Some items if we have stock, after get your payment,1-2days we can send it out; if no stock,normally need 4-6workdays for us prepare well the goods. If by express, such as DHL/Fedex/UPS, transportation time about 3-5workdays, if by sea, transportation time about 1month.

3.Good or Money can be returned?
Yes, if the goods be demaged or lost or not your size,, or other reasonable reasons,can be returned.

4.Do you have a quality guarantee or warranty?
Yes, all our products have a 12-month warranty basic on normal environment. if you need other guarantees,we can talk it , and reach an agreement.

100% factory price for you,and we warmly welcome you to visit us in the future.
