CNC steel chicken cage wire mesh welding machine
Advantage:
1.business model:factory direct sale
2.no environment pollution
3.smooth and beautiful welding spots
duct quality assurance
5.good after sales sevice
Performance characteristics:
1.This CNC cage wire mesh welding machine adopts electronic synchronous control technique,welding time and sub-control welding are all composed of digital integrated circuit,which has high control accuracy,stable performance, firm welding spots and without burned mark.
2.The CNC cage wire mesh welding machine speed is fast and the operation is simple and easy to master.
3.The weft matched with the accurate weft cutting device and accurate positioning device,ensures the weft at the same length and without being cut.
4.Mesh drowing system is controlled by servo motor which improved the precision of mesh opening size,meanwhile the longitudinal and transversal spacing are adjustable.
Main machine:
CNC steel chicken cage wire mesh welding machine
CNC steel chicken cage wire mesh welding machine
CNC steel chicken cage wire mesh welding machine
Main parameter:
| diameter | 2.0-3.2(mm) | rated voltage | AC380V50Hz |
| welding aperture | 50*50-200*200(mm) | rated power | 200KVA |
| welding width | 1200(mm) | welding speed | 0-45times/min |
| number of electrodes | 16 | overall dimension | 6*2*1.8(m) |
Finished products and usage :
It can be used for producing many kinds of cage for chicken ,mink,chick,fog and pet etc.
Auxiliary machine:
1.wire tray:put the line wire on it
sh rolling machine:make wire mesh in roll
3.wire straightening wheel:in order to make the net neat and smooth
4.wire straightening and cutting machine:straightening and cutting wire
1.Maintenance period:one year
2.If the buyers need, we can send our technical staff to the buyers’ place to debug the machine and providing the training in 30 days after the machines arrive at the destination port.
3.The commissioning fees: free
4.The training fees: USD100/day for each technical
5.The numbers of technical persons: one technical person per machines at most
6.The fees ,such as round-trip tickets, accomodation etc, are all in buyers’ account. During the maintenance period: the parts damaged non-artificially will be provided free of charge. If you need the technicians, we will assign the expertised staff to your company. And the fees,such as round-trip tickets, accomodation etc, are all in your account. After the maintenance period: If you need the machine parts, we will provide it as our cost. If you need the technicians, we will assign the expertised staff to your company. And the fees, such as round-trip tickets, accomodation etc, are all in your account.
CNC steel chicken cage wire mesh welding machine
1.Hebei Secure-Nett Fence Facility Co.,Ltd .Established in2000. In 2002 the company passed the ISO9001 quality management system certification, the end of 2006 the company has made the right to export.
2.SECURE-NETT is located in Anping ,The wire mesh base in China,with huge wire mesh industry support,All of our machines comply with international quality standards and customers'needs,and are greatly appreciated in variety of markets all over the world.
Basic information:
Business Type:manufacturer,trading company
Main products: CNC cages wire mesh welding machine;construction mesh welding machine;Fence mesh welding machine;Reinforcing mesh welding machine.
Number of employees:101-200 people
Trade&market:
Main market:Domestic market
South America
South east Asia
Eastern Europe
South Asia
Eastern Asia
Mid east Africa
Total Annual sales volum:US$50Million-US$100Million
Export percentage:61%-70%
Factory information:
Factory size:1000-3000Square meters
Factory Location: Hebei China (mainland)
No.of production lines:above10
Standards:ISO9001:2008
Pictures show:
main machine
our office
our factory
Work shop
our certificate
Before preparing the inquiry, please inform the below basic specification.So that we show the quotation
1.wire diameter from_____to_______?
2. mesh size from_______to_________?
3.welding width from______to________?
4.in roll yes____or no________?
If you have any questions, feel free to contact us:
