Model :CS-A normal double twisted barbed wire machine
CS-B Single twisted barbed wire machine
CS-C reverse twisted barbed wire machine
Technique parameter
| Item | CS-A Normal double twisted barbed wire machine |
| Motor | 1.5kw |
| Rated output | 70-120kg/h |
| Weight | 1500kg |
| Overall Dimension | 1900mmx1300mmx980mm(customized) |
| Wire collection part size | 1800mmx750mmx750mm |
| Barb space | 3",4",5" or 4",5",6" |
| Twist | 4 |
| Strand Diameter | 1.8-3.0mm |
| Wire Diameter | 1.7-2.8mm |
| Rotating Speed of Drive shaft | 432r/min |
It is suitable for loe-carbon wire, galvanized wire ,PVC coated wire.
| Item | CS-B Single twisted barbed wire machine |
| Motor | 2.2kw |
| Rated output | 50-60kg/h |
| Weight | 1200kg |
| Overall Dimension | 1900mmx1300mmx980mm |
| Wire collection part size | 1300mmx800mmx700mm |
| Barb pitch spacing | As required |
| Twist | 4 |
| Strand Diameter | 1.6-2.6mm |
| Wire Diameter | 1.6-2.2mm |
| Rotating Speed of Drive shaft | 357r/min |
It is suitable for low-carbon wire,galvanized wire
| Item | CS-C reverse twisted barbed wire machine |
| Motor | 2.2kw |
| Rated output | 50-100kg/h |
| Weight | 1200kg |
| Overall Dimension | 1900mmx1300mmx980mm |
| Wire collection part size | 1300mmx800mmx700mm |
| Barb pitch spacing | 3",4",5" or 4",5",6" |
| Twist | 4 |
| Strand Diameter | 1.5-2.8mm |
| Wire Diameter | 1.5-2.6mm |
| Rotating Speed of Drive shaft | 432r/min |
It is suitable for low-carbon wire,galvanized wire.
Our Services
1.Maintenance period:one year
2.If the buyers need, we can send our technical staff to the buyers’ place
to debug the machine and providing the training in 30 days after the
machines arrive at the destination port.
3.The commissioning fees: free
4.The training fees: USD100/day for each technical
5.The numbers of technical persons: one technical person per machines at most
6.The fees ,such as round-trip tickets, accomodation etc, are all in buyers’
account. During the maintenance period: the parts damaged non-artificially
will be provided free of charge. If you need the technicians, we will assign
the expertised staff to your company. And the fees,such as round-trip tickets,
accomodation etc, are all in your account. After the maintenance period: If
you need the machine parts, we will provide it as our cost. If you need the
technicians, we will assign the expertised staff to your company. And the fees,
such as round-trip tickets, accomodation etc, are all in your account.
Hebei Secure-Nett Fence Facility Co.,Ltd.
1.Hebei Secure-Nett Fence Facility Co.,Ltd.founded in 2000,is located in
Anping,famous as production base of wire mesh in China.
2.Now Secure-net developed into an integrated entity with R&D,manufacturing
and trading.
3.Main products of Secure-net are welding wire mesh machine,welded
wire mesh machine,chain link fence machine,barbed wire machine,gabion
mesh machine,ect.
Saleman: Gail Shi
Tel:86-18031855078
Fax:86-031185245076
Wechat:18832128285
Whatsapp:+18832128285
