high security green in color airport Y shape post fence
Airport Y shape post fence do not need any fixed parts.It is installed in a way of sequential assembly,which saves lots of time and improves effiency.
The airport Y shape post fence is treated with high adhesional electrostatic spraying polyester coating,thus,with the feature of anti-acid and anti-alkali in the outdoor environment and prolong life time.
Airport Y shape post fence make a good addition to your city,become a beautiful scenery line.
Specification of residential security wire mesh fence
| Material | hot-dipped galvanized wire |
| Height(m) | 1.6-2.0m |
| Width(m) | 2.0,2.2,2.5,3.0 |
| Wire Thickness (mm) | 2.8-6.0 |
| Hole Opening(mm) | 50*100,50*200,55*100,55*200;60*100;60*200 |
| Post Type | Y Shape Post |
| Finished | Electric galvanized,hot dipped galvanized,polyester painting,PVC coated |
| RAL Color | RAL6005;RAL6029;RAL6018;RAL5005;RAL9005;RAL3000;RAL3020 |
Base Material
1.Wire for panel adopts hot-dipped galvanized steel wire with 60g to 80g zinc coat,tensile strength above 450N to 500N.
2.Secure-Nett post uses hot-dipped galvanized steel sheet as raw material with zinc coat 80g-120g per square meter,which is strong corrosion resistance,good surface quality,uniform galvanized layer and conductive to processing.
Special Equipment
1.Welding machine
welding equipment adopts the most advanced domestic automatic welding machine.The equipment adopts synchronous control technology;points in welding and welding time control are controlled by PLC digital programming system with screen input panel makes operation more intelligent.
2.Bending machine
Bending for strengthen the panel's stability.
Modular fencing system |
Panel size (L*H) mm |
Post height mm |
Number of bending folds |
2405*1270 |
1500 |
2 |
|
2405*1570 |
1850 |
2 |
|
2405*1720 |
2130 |
2 |
|
2405*2000 |
2450 |
3 |
3.Post Machine
Post type: Y-type post.
With a wide range of beautifully crafted accessories to choose from,which can satisfy your different esthetical effect demand.Secure-net will be your ultimate to go-to designer.
4.Electrostatic spraying polyester equipment
Our company is the only one enterprise who purchases ITW GEMA electrostatic spraying polyester equipment for fence surface treatment in fence industry.To achieve ideal electrostatic spraying polyester effect,our spraying power adopts AKZO NOBEL,which manufacturer is one of the world's top 500 enterprise.It is the largest polyester power provider in the world.
Four layers surface coating treatment:
1. Hot-dip galvanizing: Extra protection against rust, corrosion;
2 Zinc phosphate: Promote the adhesion between the steel and coating film;
3. Zinc-rich epoxy powder coat: Providing long-lasting, anti-impaction and anti-corrosion;
4. Polyester color coat: With extra anti-UV rays, corrosion and self-cleaning
Product effect
Product Features
|
|
|
|
- Packaging&Shipping
It has rubber mat at the bottom of the pallet to avoid the pallet destroyed the panels.
It has 4 metal corners to keep the pallet more strong.
It has metal plate under the plastic bandage to reduce the apressure of fence panels.
wooden plate on top which can protect the fence panels avoid being crushed by other pallets
