Famous Manufacture AMEC Spring Cone Crusher With ISO Approval

Famous Manufacture AMEC Spring Cone Crusher With ISO Approval photo-1
Famous Manufacture AMEC Spring Cone Crusher With ISO Approval photo-2
Famous Manufacture AMEC Spring Cone Crusher With ISO Approval photo-3
Famous Manufacture AMEC Spring Cone Crusher With ISO Approval photo-4
Famous Manufacture AMEC Spring Cone Crusher With ISO Approval photo-5
Famous Manufacture AMEC Spring Cone Crusher With ISO Approval photo-6
US$ 20,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Cone Crusher
Application:
Mining
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or depend on clients
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Cone Crusher
Application Mining
Motor Type AC Motor
Power(W) 110kw
Capacity(t/h) 42-135
Place of Origin Jiangsu, China
Brand Name AMEC
Model Number PYZ1200
Dimension(L*W*H) 2790x1878x2844mm
Weight 25T
Certification ISO9001:2008
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

   Spring cone crusher is applied to process above medium hardness ore stone and rock. Its spring insurance system is overload protection to protect machine from damage of metal, grease and water seal are adopted, segregating stone powder and grease to guarantee stable working performance. This type of crushing chamber depends upon the purpose of mineral . The standard type (PYB) is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head type is applied to hyper fine crushing. Spring cone crusher is widely applied in metallurgy, construction, white fuel, transportation, chemical engineering and construction material to process above medium hardness ore stone and rock, it has many advantages like reliable structure, high capacity, easy to adjust, low cost, and so on.

Raw Materials:
granite, marble, basalt, iron ore, cobble, shale, bluestone, coal, cobblestone, construction material
Application:
metallurgy, construction, white fuel, transportation, chemical engineering, construction material

Advantages of Cone Crusher
1.  Increasing or reducing the number of spacer to adjust chew clearance and suspension point height. Adding spacer could change the position of cone lining and principal axis to adjust the gap.
2.  Material is in the gap of cones to get squeezed, curved and sheared to make process easier and low energy consumption.
3.  Overload protection could lengthen service life of machine.
4.  Higher speed of operation, even size of final product, cube shape of product, high capacity.



Working Principle of Cone Crusher

    Spring Cone Crusher crushes materials by the working surface between the movable cone and fixed cone, so it is more advanced and efficiency than Jaw Crusher. The movable cone is supported by spherical bearing and fixed on an hanging erect shaft which is set in the eccentric sleeve, and the sleeve is set on the stopping and pushing bearing. The movable cone and erect shaft are driven by the eccentric shaft sleeve together. The eccentric shaft sleeve is driven by horizontal shaft and fimbriated gear, and the wheel of the conveyor belt is driven by motor through v-belts. The lower part of vertical shaft is installed in the eccentric sleeve. When the eccentric sleeve rotates, there is a conical surface lined out by the shaft. When the movable cone comes near the fixed cone, rocks are grinded into pieces, when the cone leaves, pulverized materials is discharged from the discharge hole. The fixed cone can be ascended or descended by adjusting.

Famous manufacture AMEC spring cone crusher with ISO Approval

Specification and Technical Parameter of PY Series Cone Crusher:
ModelDiameter of Bottom End of Conical Crushing Head(mm)Max Feeding Size(mm)Adjustable Range of Discharge Opening(mm)Capacity(t/h)Motor Power(kw)Rev.of Eccentric Shaft(r/min)Weight(t)Dimension (L×W×H)(mm)
PYB600Φ6007512-1520-408P-3035652234×1370×1675
PYD600Φ600353-1312-238P-303565.52234×1370×1675
PYB900Φ90011515-5050-908P-5533311.22692×1640×2350
PYZ900Φ900605-2020-658P-5533311.22692×1640×2350
PYD900Φ900503-1315-508P-5533311.32692×1640×2350
PYB1200Φ120014520-50110-1688P-11030024.72790×1878×2844
PYZ1200Φ12001008-2542-1358P-110300252790×1878×2844
PYD1200Φ1200503-1518-1058P-11030025.32790×1878×2844
PYB1750Φ175021525-50280-4808P-16024550.33910×2894×3809
PYZ1750Φ175018510-30115-3208P-16024550.33910×2894×3809
PYD1750Φ1750855-1375-2308P-16024550.23910×2894×3809
PYB2200Φ220030030-60590-10008P-(260-280)220804622×3302×4470
PYZ2200Φ220023010-30200-5808P-(260-280)220804622×3302×4470
PYD2200Φ22001005-15120-3408P-(260-280)22081.44622×3302×4470






Famous manufacture AMEC spring cone crusher with ISO ApprovalFamous manufacture AMEC spring cone crusher with ISO ApprovalFamous manufacture AMEC spring cone crusher with ISO ApprovalFamous manufacture AMEC spring cone crusher with ISO ApprovalFamous manufacture AMEC spring cone crusher with ISO ApprovalFamous manufacture AMEC spring cone crusher with ISO ApprovalFamous manufacture AMEC spring cone crusher with ISO ApprovalFamous manufacture AMEC spring cone crusher with ISO Approval
Packaging & Shipping

Nude packing for the main machine

Wooden case for the power motor and spare parts



Our Services

       We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support  and after service.

Company Information



      Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.



Our main scope of our business:

Machinery and Equipment:

Power machinery, agricultural machinery, garden machinery, construction machinery, mining machine,machine tools and complete equipment

Power Transmission Parts

Chains, sprockets, taper bushes, gears and shafts



OEM components:

Machined, forged, cast, punched and welded workpiece

Micro Motors

Step motors, DC brushed & brushless motors, AC motors for aircon and paper shredder

Automobile Accessories

Auto lens and lamps, mirrors, motors and mechanical parts



Keeping the customers satisfied has been our strong wish. Please contact us for more information. We welcome your orders.
