The ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc, and the ball mill can grind various ores and other materials with dry type and wet type. There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material.
Raw Materials:
Limestone, calcite, barite, dolomite, potassium feldspar, marble, talcum, gypsum, kaolin, bentonite, medical stone, rock phosphate, manganese ore, iron ore, copper ore, gold ore,quartz, active carbon, carbon black, ceramic, coal, etc. .
Application:
Cement, silicate product, new building materials, refractory material, chemical fertilizer, nonferrous and ferrous metal beneficiation and glass ceramic industries.
Advantages of Ball Mill:
1.Reasonable discharge port design, de-ironing separator could be set according to clients’s requirement.
2. High manganese steel plate is more wear-resisting and it has longer service life.
3. Pinion drives rack wheel rotating.
4. High quality and national standard reduction box.
Working Principle of Ball Mill:
This machine is barrel horizontal type rotation device, outer gear transmission, and two bins. Raw material is taken to first bin from feeding port through hollow shaft, there are stepped lining plate and corrugated plate inside the bin and different size of steel ball, steel ball is taken to a certain height by the force of centrifugal which is caused by barrel's rotation, material will be impacted and grinded. After coarse grinding process in the first bin, material will be delivered to the secondary bin. There are plane liner and steel ball to further grind the material. Powder material will be discharged from discharging grate plate and the grinding process is completed.
Specification and Technical Parameter of Ball Mill
| Model | Rotate Speed(r/min) | Ball Load(t) | Feeding Size(mm) | Discharge Size(mesh) | Capacity(t/h) | Power(kw) | Weight(t) |
| Φ900×1800 | 36-38 | 1.5 | ≤20 | 48-200 | 0.37-2.1 | 18.5 | 3.6 |
| Φ900×2400 | 36.4 | 2.1 | ≤20 | 48-200 | 0.5-2.4 | 18.5 | 4.8 |
| Φ900×3000 | 36 | 2.7 | ≤20 | 48-200 | 0.8-2.5 | 22 | 5.3 |
| Φ900×3500 | 36 | 2.7 | ≤20 | 48-200 | 1.1-3.8 | 37 | 5.8 |
| Φ1200×1200 | 32.1 | 2.4 | ≤25 | 48-200 | 0.8-1.6 | 30 | 8.5 |
| Φ1200×2400 | 31.38 | 3 | ≤25 | 48-200 | 1.4-2.8 | 45 | 11.4 |
| Φ1200×3000 | 31.38 | 3.5 | ≤25 | 48-200 | 1.6-3 | 45 | 12.1 |
| Φ1200×3500 | 32.4 | 5 | ≤25 | 48-200 | 1.6-3.5 | 55 | 12.7 |
| Φ1200×4500 | 31.8 | 6.5 | ≤25 | 48-200 | 1.83-3.9 | 55 | 13.1 |
| Φ1500×3000 | 29.2 | 9.7 | ≤25 | 48-200 | 2.8-9 | 95 | 14.8 |
| Φ1500×3500 | 29.58 | 10.8 | ≤25 | 48-200 | 3.1-9.7 | 95 | 15.8 |
| Φ1500×4000 | 29.58 | 12 | ≤25 | 48-200 | 4.8-10 | 110 | 17.9 |
| Φ1500×4500 | 29.58 | 13.5 | ≤25 | 48-200 | 4.8-11 | 110 | 19.9 |
| Φ1500×5700 | 30.15 | 15 | ≤25 | 48-200 | 5-16 | 130 | 23.4 |
| Φ1500×6400 | 30.15 | 16 | ≤25 | 48-200 | 5.4-17.8 | 155 | 25.4 |
| Φ1830×2400 | 25.4 | 10 | ≤25 | 48-200 | 4-10 | 130 | 23.7 |
| Φ1830×3000 | 26.3 | 14.4 | ≤25 | 48-200 | 4.5-10.5 | 130 | 26.6 |
| Φ1830×3600 | 25.4 | 15.2 | ≤25 | 48-200 | 5.3-10.8 | 155 | 27.6 |
| Φ1830×4000 | 25.4 | 16.9 | ≤25 | 48-200 | 6-11 | 180 | 29.4 |
| Φ1830×4500 | 25.4 | 20 | ≤25 | 48-200 | 6.8-11.5 | 180 | 30.4 |
| Φ1830×6400 | 24.1 | 21 | ≤25 | 48-200 | 7-12 | 210 | 32.3 |
| Φ1830×7000 | 24.1 | 23 | ≤25 | 48-200 | 7.8-13.8 | 245 | 34.2 |
| Φ2100×3000 | 24.35 | 19.8 | ≤25 | 48-200 | 5.8-14 | 155 | 32.3 |
| Φ2100×3600 | 23.7 | 20 | ≤25 | 48-200 | 7-20 | 210 | 33.8 |
| Φ2100×4000 | 24.98 | 21 | ≤25 | 48-200 | 9-22 | 210 | 35 |
| Φ2100×4500 | 23.7 | 24 | ≤25 | 48-200 | 9.5-32 | 245 | 40 |
| Φ2100×6000 | 24.98 | 33 | ≤25 | 48-200 | 10-36 | 280 | 47.5 |
| Φ2200×4500 | 24.98 | 27 | ≤25 | 48-200 | 7-16 | 280 | 46.5 |
| Φ2200×5500 | 21 | 30 | ≤25 | 48-200 | 10-22 | 370 | 48.5 |
| Φ2200×6500 | 21.7 | 32 | ≤25 | 48-200 | 14-26 | 380 | 50.2 |
| Φ2200×7000 | 21.7 | 33 | ≤25 | 48-200 | 15-28 | 380 | 51.3 |
| Φ2200×7500 | 21.7 | 35 | ≤25 | 48-200 | 15-30 | 380 | 53.2 |
| Φ2400×3000 | 21 | 25.8 | ≤25 | 48-200 | 7.8-18 | 245 | 51.3 |
| Φ2400×4500 | 21 | 30 | ≤25 | 48-200 | 13.7-28 | 320 | 61.7 |
| Φ2700×2100 | 21.7 | 23 | ≤25 | 48-200 | 8.5-17 | 260 | 69 |
| Φ2700×3600 | 21.7 | 37 | ≤25 | 48-200 | 11-27 | 400 | 86 |
| Φ2700×4000 | 21.37 | 40 | ≤25 | 48-200 | 15-28 | 475 | 89 |
| Φ2700×4500 | 21.37 | 48 | ≤25 | 48-200 | 16.5-36 | 475 | 97 |
| Φ3200×3000 | 18.6 | 46 | ≤25 | 48-200 | 15.5-33 | 500 | 112 |
| Φ3200×3600 | 18.6 | 56 | ≤25 | 48-200 | 17.5-40 | 630 | 118 |
| Φ3200×4500 | 18.6 | 65 | ≤25 | 48-200 | 24-49 | 800 | 130.5 |
| Φ3600×3900 | 17.8 | 75 | ≤25 | 48-200 | 25-53 | 1000 | 152.9 |
| Φ3600×4500 | 17.8 | 88 | ≤25 | 48-200 | 29-65 | 1250 | 165 |
| Φ3600×6000 | 17.8 | 117 | ≤25 | 48-200 | 35-80 | 1600 | 196 |
| Φ4000×5000 | 16.4 | 101 | ≤25 | 48-200 | 46-97 | 1600 | 248 |
Nude packing for the main machine
Wooden case for the power motor and spare parts
We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support and after service.
Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.
Our main scope of our business:
Machinery and Equipment:
Power machinery, agricultural machinery, garden machinery, construction machinery, mining machine,machine tools and complete equipment
Power Transmission Parts
Chains, sprockets, taper bushes, gears and shafts
Keeping the customers satisfied has been our strong wish. Please contact us for more information. We welcome your orders
