Dongfeng DF604 Tractor

Dongfeng DF604 Tractor thumbnail-1
Dongfeng DF604 Tractor photo-1
US$ 3,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Wheel Tractor, 4-cylinder,Upright inline cylinder
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Wheel Tractor, 4-cylinder,Upright inline cylinder
By wheel 4WD
Usage Farm Tractor
Drive Type Other, Gear Drive, 4WD
Power(W) 60hp
Certificate EEC
Brand Name DongFeng
Model Number DF604 Tractor
Place of Origin Hubei, China
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Dongfeng DF604 Tractor
Best performance ; High quality with reasonable price
Convenient operation ;
For low mine usage
Exce

Dongfeng DF604 Tractor







Tractor Parameters

Model

DF-604

Drive Type

4WD

Overall Dimensions L*W*H(mm)

3890*1828*2400 (Height to steering wheel)

Wheel Track(mm)

Front

1420

Rear

1450-1650(1450)

Wheel Base(mm)

2080

Ground Clearance(mm)

Under Front Axle

353

Under Rear Axle



Rated Traction Force(N)

14500

Construction Mass(Kg)

2380

Min. Turning Radius(m)

4.1

Theoretical Speed(no creeper)

Forward(km/h)

1.63,2.70,3.47,5.49,10.29,7.07 9.10,14.40,1.26,18.57,23.88,37.80

Reverse(km/h)

4.34,7.199.24,14.63

Theoretical Speed(with creeper)

Forward(km/h)

0.30,0.49,0.64,1.00,0.79,1.30 1.67,2.64,.207,3.41,4.38,6.94

Reverse(km/h)

0.80,1.32,1.70,2.69

Engine Specifications

Model

CZ4102T, YTR4105T, LR4108T

Type

4-cylinder,Upright inline cylinder radiator cooling,4-storke cycle, direct-injection

Rated Power(Kw/hp)

44.1/60.0

Rated Fuel Consumption(g/kw/h)

<242

Rated Speed(rpm)

2300

Bore*Stroke(mm)

105*125

Total Displacement(L)

4.33

Drive System

Clutch

Dry Linkage type dual shift Function clutch

Gear Box

4*(3+1),sleeve gear

Main Drive

One Pair of Spiral Bevel gears

Differential

Bevel Gear

Differential Lock

sliding pin, foot operated

Final Transmissions

planetary reduction gear

Travelling Mechanism

Tyre

front

8.3-24

rear

14.9-28

Steering Gear

Hydraulic steering

Brake

Wet disc(Multiple)

Working Device

Hydraulic System

Lifting Capacity at 610 mm Behind Lift Point(Kg)

1200

3-point Suspension

Category: II

P.T.O. Shaft

Rotating Speed(rpm)

540/1000

Spline size

6-φ35 Rectangular spline
