Specifications
Drawable backhoe:1. Powered by 11.5/13HP engine or PTO
2. Available accessory: backfill blade, ripper, thumb, etc
3. Towable
FMTB-001 drawable backhoe specifications:
Modle | FMTB-001 drawable backhoe | ||
Transport Overrall dimension(L×W×H/mm) | 3200x1540x2050 | ||
Net weight(kg) | |||
Working pressure(Mpa) | 20 | ||
Towable backhoe engine | Modle | diesel engine | |
Type | Single-cylinder4-strokeWater cooling | ||
Power(Kw/Hp) | 8.5/11.5 | ||
Speed(r/min) | 2400 | ||
Net weight(kg) | 600 | ||
Displacement | 0.598 | ||
Ignition | Transistor electronic | ||
Certificate | EPA/CE | ||
Digger specifications | Max.digger depth(mm) | 2200 | |
Max.digger hight mm | 2700 | ||
Max.digger power(kg) | 800 | ||
Max.unload hight(mm) | 1600 | ||
Transport height(mm) | 1900 | ||
Max.digger radius(mm) | 3100 | ||
Loading reach(mm) | 1400 | ||
Bucket rotation(°) | 150 | ||
Arm swing arc(°) | 140 | ||
Bucket Size | 200 | ||
Bucket Capacity | 0.03 | ||
Pump | Modle | CBN-G310 | |
Displacement volumeml/r) | 10-14 | ||
Rated pressure(Mpa) | 16-20 | ||
Rated Speed(r/min) | 2000 | ||
FMTB-002 drawable backhoe specifications:
Modle | FMTB-002 drawable backhoe | |||
Transport overrall dimension(L×W×H)(mm) | 3200x1540x2050 | |||
Net weight(kg) | ||||
Working pressure(Mpa) | 20 | |||
Towable backhoe engine | Modle | Pertrol engine(JF390) | ||
Type | single-cylinder4-stroke | |||
Rated power(Kw/Hp) | 9.6/13 | |||
Rated speed(rpm) | 2500 | |||
Net weight(kg) | 31 | |||
Displacement volume(L) | ||||
Ignition | Transistor electronic | |||
Certificate | EPA/CE | |||
Digger specifications | Max.digger depth(mm) | 2200 | ||
Max.digger hight mm | 2700 | |||
Max.digger power(kg) | 800 | |||
Max.unload hight(mm) | 1600 | |||
Transport height(mm) | 1900 | |||
Max.digger radius(mm) | 3100 | |||
Loading reach(mm) | 1400 | |||
Bucket rotation(°) | 140 | |||
Arm swing arc(°) | 150 | |||
Bucket Size | 200 | 300 | 400 | |
Bucket Capacity | 0.03 | 0.04 | 0.05 | |
Pump | Modle | CBN-G310 | ||
Displacement volume(ml/r) | 10-14 | |||
Rated pressure(Mpa) | 16-20 | |||
Rated speed(r/min) | 2000 | |||
FMTB-003 drawable backhoe: driven by tractor PTO system.
With low price and high quality, our drawable backhoes are best sold in Australia, USA, South Africa, etc for earth moving, hole digging, ditch cleaning and many other applications. Our towable backhoe is very easy to be operated and with very less maintenance requirement. It brings big convenience to your farm or garden work.
We also offer 3 point hitch backhoe LW-6, LW-7 and LW-8 with 6~8 inches arm reach.
