FOTMA FM920F 2.0T wheel loader
Introduce:
FOTMA FM920F 2.0t wheel loader
Feature
1.Hydrostatic transmission can give full play to the engine power. according to the load changes, it
regulates automatically the output torque. It has the advantages of high work efficiency and easy to repair,
2.Optimal design of working device makes it possess the super lift and high automatic-release function;
3. All wheel drive leads to large driving force;
4.Articulated frame structure and small turning radius make it convenient to operate although in a narrow space;
5.Equipped with brake system of single Road gas cap oil;
6.Back axle can rotate around the center swing hanger, so it can improve the pass-through performance;
7.The infinitely variable speeds and hydraulic load sensing steering system is stable and reliable .
Total performance parameters |
|
|
Bucket capacity |
1.1 |
m3 |
Loading mass |
2000 |
kg |
bucket lifting time |
4 |
s |
Total cycling time |
9 |
s |
Max climb ability |
30 |
' |
Articulated steering angle |
35 |
' |
Turning radius (Bucket tip lateral) |
5048 |
mm |
Max dumping height |
3000 |
mm |
Max dumping distance |
940 |
mm |
Min.ground clearance |
320 |
mm |
Breakout force |
65 |
KN |
Max towing force |
50 |
KN |
Model |
LR4108G97 |
|
Rated power |
60 |
KW |
Rated speed |
2400 |
r/min |
Overall length |
5850 |
mm |
Overall width |
2070 |
mm |
Overall height |
2740 |
mm |
Wheelbase |
2100 |
mm |
Tread |
1520 |
mm |
Tyre size |
16/70_20 |
|
Total mass |
6000 |
kg |
