14.0 Ton Forklift

14.0 Ton Forklift thumbnail-1
14.0 Ton Forklift thumbnail-2
14.0 Ton Forklift thumbnail-3
14.0 Ton Forklift thumbnail-4
14.0 Ton Forklift thumbnail-5
14.0 Ton Forklift photo-1
14.0 Ton Forklift photo-2
14.0 Ton Forklift photo-3
14.0 Ton Forklift photo-4
14.0 Ton Forklift photo-5
US$ 10,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
HC
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name HC
Model Number HC series
Type Powered Pallet Truck
Power Souce Other, Diesel
Rated Loading Capacity 14Ton
Max. Lifting Height 6000mm
Min. Lifting Height 250mm
Fork Length 1820mm
Fork Width 200mm
Certification CE

Specifications

R Series 14 ton Forklift T
High quality with reasonable price
Excellent performance goog ater-sales service

14T Diesel Forklift Specification
1 Model   CPCD140-W2 CPCD140-W25
2 Power type   Diesel Diesel
3 Rated capacity kg 14000 14000
4 Load center mm 900 900
5 Folk Spread(outside) Min/Max mm 520-2200 520-2200
6 Lift height mm 3000 3000
7 Free lift height mm 0 0
8 Fork size L*W*T mm 1820*200*105 1820*200*105
10 Fork overhang (Wheel center to fork face) mm 890 890
17 Turning radius (outside) mm 5000 5000
19 Speed Travel (No load) km/h 27 27
20 Travel (Full load) km/h 22.5 22.5
21 Lifting (Full load) mm/sec 350 350
22 Lowering (Full load) mm/sec 420 420
23 Max. Drawbar Pull (Full load) N 130000 130000
24 Max. gradeability (Full load) % 25 25
25 Tyres Front (4) mm 12.00-24-20PR 12.00-24-20PR
26 Rear (2) mm 12.00-20-20PR 12.00-20-20PR
29 Wheelbase mm 3650 3650
30 Ground clearance Mast   250 250
31 Wheelbase center   320 320
32 Self weight kg 22700 22700
37 Battery Voltage/Capacity(20HR) V/AH 2*12/150 2*12/120
38 Engine Model   6BTA5.9 QSB6.7
39 Manufacture   Cummins Cummins
40 Rated output kw/rpm 138/2300 142/2300
41 Rated torque N m /rpm 786/1500 930/1500
42 No. of cylinder   6 6
43 Bore*stroke mm 102*120 107*124
44 Displacement L 5.9 6.7
45 Fuel tank capacity L 280 280
46 Trans-missions Manufacture   German German
47 Type   Electric control Powershift Electric control Powershift
