Magnetic Stirrer Hot Plate

Magnetic Stirrer Hot Plate thumbnail-1
Magnetic Stirrer Hot Plate thumbnail-2
Magnetic Stirrer Hot Plate thumbnail-3
Magnetic Stirrer Hot Plate thumbnail-4
Magnetic Stirrer Hot Plate thumbnail-5
Magnetic Stirrer Hot Plate thumbnail-6
Magnetic Stirrer Hot Plate photo-1
Magnetic Stirrer Hot Plate photo-2
Magnetic Stirrer Hot Plate photo-3
Magnetic Stirrer Hot Plate photo-4
Magnetic Stirrer Hot Plate photo-5
Magnetic Stirrer Hot Plate photo-6
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
WJ
Model Number:
WA-Baisc
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Changzhou W&J Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or other
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name WJ
Model Number WA-Baisc
Place of Origin Shanghai, China

magnetic stirrer hot plate



magnetic stirrer hot plate

magnetic stirrer hot plate

magnetic stirrer hot plate

- Stainless steel with ceramic coated hotplate resists to corrosion

- Separated safety circuit, automatically stop heating when temperature over 350℃

- Motor with electronic speed control, constant speed even during changes in load

- Variable speed of motor

- High magnetic adhesion, prevent the stirrer bar escape

- Enclosed assembly with protection class IP42 and DC brushless motor guarantees long service



Technical Data

WA-BASIC

Voltage

100-120/200-240V

Frequency

50/60HZ

Power

430W

Stirring point position quantity

1

Max stirring quantity (H2O)

20L

Max magnetic bar

80mm

Motor type

Exterior rotor brushless motor

Motor rating input

18W

Motor rating output

10W

Speed range

0 – 1500RPM

Speed display

Scale

Material of plate

Porcelain Enamel

Dimension of Plate

φ135mm

Heating Power

400W

Heating Rate (1L water)

6K/min

Temperature range

Room Temp ~ 340℃

Safety circuit (heating plate)

350℃

Dimension (W×D×H)

280×160×85mm

Weight [kg]

2.8

Permissible ambient temperature

5~40℃

Permissible relative humidity

80%

Protection class acc. to DIN EN60529

IP42





magnetic stirrer hot platemagnetic stirrer hot platemagnetic stirrer hot platemagnetic stirrer hot plate
