Mini Wheel Loader

Specifications

Mini Wheel loader

Specifications of ZL08B Wheel Loader:

1.0 Engine details

(1) Model: Changcai L24

(2) Engine type: In-line arrangement, water-cooled, one-cycle diesel Engine

(3) Rated Power: 17KW (23.12 H.P.)

(4) Rated Speed: 2200 r/min (rpm)

(5) Fuel Consumption ratio in standard working condition: 269g/kw.h

2.0 Steering System

(1) Cycloid full hydraulic steering system: BZZ-80

(2) System Pressure: 10MPa

(3) Steering Cylinder: Φ76x Φ63x160

3.0 Bucket

(1) Bucket Capacity: 0.4 m3

(2) Bucket width: 1300mm

(3) Bucket type: Heavy-duty bolt on teeth

(4) Max. Breakout Force: 22.5KN

(5) Rated Load: 800kg

(6) Operating Weight: 2000kg

4.0 Overall Dimensions

(1) Overall Length (Bucket on ground position): 4480mm

(2) Overall Height

(a) Ground to Cab Top: 2200mm

(b) Ground to exhaust pipe: It is below from the top of cabin

(c) Dumping Height: 2300mm

(3) Overall Width: 1400mm

5.0 Operating Specifications

(1) Drive Means: Two-wheel drive

(2) Min Turning Radius: 3000mm

(3) Driving System: mechanical

(4) Dumping Height: 2300mm

(5) Dumping Reach at max height: 900mm

(6) Min Base to the ground: 220mm

(7) Time of raise: 4.5sec.

(8) Hydraulic cycle time: 8.5sec.

6.0 Brake System

(1) Service Brake: mechanical brake

(2) Parking Brake: Hand operated

7.0 Tyre:

(1) Model: 7.50-16 (2) Width: 18cm (3)Diameter: 78cm

8.0 Wheelbase: 1620mm

9.0 Track: 1160mm
