ZL08A Wheel Loader,800kg Mini Loader

Specifications

Specification of ZL08A Wheel Loader

1.0 Engine Details

(1) Model: Changcai L22

(2) Engine type: In-line arrangement, water-cooled, one-cycle diesel Engine

(3) Rated Power: 15.5KW (21.08 HP)

(4) Rated Speed: 2200 r/min (rpm)

2.0 Steering System

(1) Cycloid full hydraulic steering system: BZZ-80

(2) System Pressure: 10MPa

3.0 Bucket

(1) Bucket Capacity: 0.4 m3

(2) Bucket width: 1300mm

(3) Max. Breakout Force: 21KN

(4) Rated Load: 800kg

(5) Operating Weight: 2000kg

4.0 Overall Dimensions

(1) Overall Length (Bucket on ground position): 4480mm

(2) Overall Height

(a) Ground to Cab Top: 2200mm

(b) Ground to exhaust pipe: It is below from the top of cabin

(3) Overall Width: 1400mm

5.0 Operating Specifications

(1) Drive Means: Rear-wheel drive

(2) Min Turning Radius: 3000mm

(3) Driving System: mechanical

(4) Dumping Height: 2300mm

(5) Dumping Reach at max height: 900mm

(6) Min the ground distance: 220mm

(7) Time of raise: 4.5sec.

(8) Hydraulic cycle time: 9second.

6.0 Brake System

(1) Service Brake: Mechanical brake

(2) Parking Brake: Hand operated

7.0 Tyre

(1) Model: 7.50-16 (2) Width: 18cm (3) Diameter: 78cm

8.0 Wheelbase: 1620mm

9.0 Track: 1160mm
