Help CenterSWM610 Wheel Loader With CE Mark
Related Products
Specifications
wheel loaderwheel loader
SWM610 is our new model, and pay more attention to our quality, control system, have much higher cost performance, used important Japanese YANMAR engine, CE standard , design novel and unique.
SWM610 wheel loader Specfication:
Rate load(kg):1000
Bucket capacity:0.5
Wheel Distance(mm):1170
Axle-base(mm):1790
Loader clearance radius(mm):4450
Min Base to the ground(mm):240
Ascent(mm):3500
Dump clearanle(mm):2300
Distance acc.to the height(mm):1080
Time of Raise(s):4
Hydraulic cycle time(s):9
Turns to pick the strength most greatly(KN):32
Drive Means:Four Wheel Drive
Operating weight(kg):2500
Overall dimensions(Length*width*height)(mm):4530*1500*2500
Biggest deflection angle°:35°
Engine Model:YANMAR 4TNV88-BSBKC
Engine Rated power(kw):25.2
Engine Rated output(rpm):2200
