Help CenterSWM620 Wheel Loader for Sale
Related Products
Specifications
wheel loader SWM620 for saleRated load :2000kg
Engine Weichai4108G94A
Hydro-mechanical transmission
Joystick valvle
Features
1. The wheel loader uses a hydro-mechanical transmission which can make full use of engine power and can have an automatic variable transmission according to the external resistance. It avoids power failure of the engine due to the suddenly increased external load. The wheel loader can absorb and eliminate the vibration and impact of external load on engine. It protects the drive system and engine, increases the service life, facilitates the operation and achieves higher economical and production efficiency.
2. The wheel loader uses a central articulated frame and load sensing hydraulic steering gear. The machine can achieve a short turning radius and superposition of the front and rear tracks upon turning (this will ensure safe driving). The wheel loader has the advantages of easy operation on narrow sites, flexible operation, safety, convenient maintenance and so on.
3. The wheel loader uses four-wheel drive, low-pressure wide base off-road tires and an oscillating rear axle, so it has sound off-road performance, good traffic ability andlarger traction.
4. The wheel loader is equipped with a single-pipe type hydraulic four-wheel brake.
5. The wheel loader has a fully enclosed cab and the seats have the functions of vibration reduction and easy adjustment. The machine offers the driver a comfortable drive and wide view.
Technical Specifications
Main Technical Parameter of SWM620 | |
| Item | Parameter |
| Rated load (kg) | 2000 |
| Bucket capacity (m3) | 1.2 |
| Wheel tread (mm) | 1470 |
| Wheel base (mm) | 2160 |
| Min turning radius (mm) | 5200 |
| Min ground clearance (mm) | 340 |
| Dumping height (mm) | 2600 |
| Corresponding dumping reach (mm) | 1140 |
| Lifting time (s) | 6 |
| Hydraulic cycle time (s) | 10 |
| Maximum excavating force (KN) | 37.75 |
| Drive mode | Four are Drive |
| Machine weight (kg) | 5310 |
| Overall dimensions (mm) (Length*width*height) | 5630*2100*2850 |
| Engine model | Weichai4108G94A |
| Rated power of engine (kw) | 60 |
| Rated speed of engine (rpm) | 2400 |
The SWM620 Wheel Loader can fit in Quick Hitch ,All kinds of working device ,Pallet Fork. Meets your needs perfectly.
