Home > Transportation > Forklifts & Parts > Forklift > Diesel Truck

Diesel Truck

Diesel Truck thumbnail-1
Diesel Truck photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
SWLTD
Contact Supplier Request Quote Chat Now
Shandong Weili World Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name SWLTD
Model Number CPC30
Type Manual Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 3000KGS
Max. Lifting Height 2720mm
Min. Lifting Height 260mm
Fork Length 1070mm
Fork Width 130mm
Overall Dimensions 4585*1700*2720(mm)
Certification ce

Specifications

diesel truck
.patented products
2.internal combusition
3.Streamlined body

diesel truck

category

 Item

Unit

specification



general situation

Habitat

Qingzhou shandong

 Model



CPC30

 power form

diesel

Rate Load

Kg

3000

Load Center

mm

500

basic size

lifting altitude

mm

3000

lifting freely altitude

mm

145

fork size

L x W x T

mm

1070 X 130 X 45

distance between the forks

Min ·/Max

mm

290-1200

mast tilt angle

F/R

deg

6/12

Front overhang

mm

480



Size

 length

mm

2885

 width

mm

1230

height when portal not lift

mm

2182

height when portal lift

mm

4040

reliefbracket height

mm

2160

min.tuming radius

mm

2540

min right angle aisle width

mm

2490

Minimum stacking right Angle channel width

mm

3020+F+J

performance

speed

drive speed (no-load)

Km/h

21

drive speed (load)

mm/s

490

max. climbing power

%

20

 weight

Kg

4300

tire

tire

front wheel



8.25-12-12PR

rear wheel



6.50-10-10PR

wheelspan

front wheel

mm

1030

rear wheel

mm

974

axle distance

mm

1760

Minimum Ground Clearance

mm

120

Power and transmission

accumulator

pressure

V/Ah

12/105

Engine

model



490BPG-53

habitat

Xinchai

output power

Kw/r·p·m

37/2650

rated torque

N·m/r·p·m

148/1900

no. of cylinder



4

cylinder x schedule

mm

90 X 100

air displacement

cc

2540

fuel-tank capacity

L

65

minimum specific fuel consumption

g/kw·h

238

transmission

habitat

Chasha zhongnan

gears(front/after)



3/2

working pressure

Mpa

16















 Above is the forklift specification,Any questions ,No hesitate to contact me,or call me directly.
