Forklift Price ,diesel Forklift CPC30 for Sale
US$ 7,000 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
SWLTD
Model Number:
CPC30
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shandong, China
Brand Name
SWLTD
Model Number
CPC30
After-sales Service Provided
Overseas service center available
Specifications
CPC30 forklift with CE mark Diesel ,Automatic catch Forklift1)Patent product
2)Streamlined body
3)Functions excellent
Features
1. The large-size CPC30 diesel forklift truck is a counter balanced type. It features sound stability and no limitation on service time. The internal combustion forklift truck is used for heavy loads and is often used outside. Its diesel motor has the advantages of better performance (low speed, strong overload ability and strong long-time working ability) and low fuel cost.
2. With its unique appearance, the machine has a stream-line effect and the advantages of low noise, vibration reduction, comfort, safety and dustproof. The forklift truck can match with various fork trucks with different hydraulic and mechanical transmission systems according to the needs.
3. Using the full hydraulic steering device theinternal combustion forklifttruck can achieve a small turning radius and features easy steering and safety.
Parameters of CPC30
| Classification | Item | Organization | Parameters | ||
| Overview | Place of origin | Qingzhou, Shandong Province | |||
| Model | CPC30 | ||||
| Power form | Diesel fuel | ||||
| Rated load | Kg | 3000 | |||
| Load center | mm | 500 | |||
| Basic dimension | Lifting height | mm | 3000 | ||
| Free lift height | mm | 145 | |||
| Fork dimension | L x W x T | mm | 1070 X 130 X 45 | ||
| Fork spacing (lateral) | Min /Max | mm | 290-1200 | ||
| Mast tilt angle | F/R | deg | 6/12 | ||
| Front overhang | mm | 480 | |||
| External dimension | Total length | mm | 2885 | ||
| Total width | mm | 1230 | |||
| Mast lowered height | mm | 2182 | |||
| Mast raised height | mm | 4040 | |||
| Overhead guard height | mm | 2160 | |||
| Min turning radius | mm | 2540 | |||
| Min width of intersecting aisle | mm | 2490 | |||
| Min width of right-angle stacking channel | mm | 3020+F+J | |||
| Property | Velocity | Travel speed (empty load) | Km/h | 21 | |
| Lifting speed (full load) | mm/s | 490 | |||
| Max climbing ability | % | 20 | |||
| Dead weight | Kg | 4300 | |||
| Tire | Radial Tire | Front wheel | 8.25-12-12PR | ||
| Real wheel | 6.50-10-10PR | ||||
| Wheel tread | Front wheel | mm | 1030 | ||
| Real wheel | mm | 974 | |||
| Wheel base | mm | 1760 | |||
| Min ground clearance | mm | 120 | |||
| Power and transmission | Storage battery | Voltage | V/Ah | 12/105 | |
| Engine | Model | 490BPG-53 | |||
| Place of origin | Xinchai Power, Zhejiang Province | ||||
| Output power | Kw/r.p.m | 37/2650 | |||
| Rated torque | N.m/r.p.m | 148/1900 | |||
| Number of cylinders | 4 | ||||
| Cylinder bore X travel | mm | 90 X 100 | |||
| Displacement | cc | 2540 | |||
| Oil tank capacity | L | 65 | |||
| Min fuel consumption rate | g/Kw.h | 238 | |||
| Transmission | Place of origin | Zhongnan Transmission, Changsha City | |||
| Gear (front and rear) | 3/2 | ||||
| Operating pressure | Mpa | 16 | |||
Factory
Certificates & Honors
BAUMA CHINA 2012 IN SHANGHAI
Shipping in Qingdao Port
Dear Freinds,welcome to our site ,may this is the beginning of our mutual benefit business .
Wecome your excellent inquiry .
You can call 0086 532 89096580 or 0086 158 6427 9137 ,we are here for you all the time .
