4 seater electric golf car with revised seats
| Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration) | |||||||
| Body and Frame | |||||||
| Frame | Welded steel framework with phosphate+electro-coating treatment | ||||||
| Body | PP plastic front body + PP plastic rear body | S | |||||
| Roof | FRP | S | |||||
| Plastic | O | ||||||
| Windshield | one-piece Organic glass | S | |||||
| Windshield, hinged | O | ||||||
| Laminated windshield | O | ||||||
| Laminated windshield with wiper | O | ||||||
| Stainless steel package | including front upright, rear upright, caddie handle | O | |||||
| Aluminum roof support | including front upright, rear upright, caddie handle | O | |||||
| 2point seat belt | O | ||||||
| Large Seats: | |||||||
| 1) backrest and cushion | Rebond seat + artificial leather | S | |||||
| 2) armrest | Formed | S | |||||
| 3) plastic seat bottom | S | ||||||
| Formed seat&backrest vinyl | not include rear flip-flop seat | O | |||||
| Backrest cover in wood finish | O | ||||||
| Floor | rubber | S | |||||
| Dashboard in black plastic | forward/reverse switch, battery capacity indicator, ignition key | S | |||||
| Dashboard in wood finish | O | ||||||
| Steering wheel in wood finish | O | ||||||
| Beverage holders | 4 cups drink holders | S | |||||
| Glove box | S | ||||||
| Glove box door (include two locks) in black plastic | 2 doors per set | O | |||||
| Glove box door (include two locks) in wood finish (inside and outside) | 2 doors per set | O | |||||
| Side trim | Aluminum | S | |||||
| Score card holder | on steering wheel | S | |||||
| Towing bracket | on front of golf car | S | |||||
| Inner rear view mirror | One piece per cart in the middle of the windshield | O | |||||
| Side rear view mirror | Two pieces per cart | O | |||||
| Battery watering system,48V system | without water supply tool | O | |||||
| Battery watering system,36V system | without water supply tool | O | |||||
| Manual Pump | water supply tool (other water supply tools are available) | O | |||||
| Overshadowing Curtain | O | ||||||
| Enclosure | O | ||||||
| Electric system | |||||||
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn. | S | |||||
| Reversing alarm | S | ||||||
| Meter(only available for 48V system) | speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator | O | |||||
| Police Light | O | ||||||
| 12V accessory plug | to be mounted on the dashboard | O | |||||
| Hour meter | O | ||||||
| Solar Panel | 48V, 185W | O | |||||
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A | S | |||||
| Steering and Suspension | |||||||
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function | S | |||||
| Right hand drive system | O | ||||||
| Brake system | Mechanical brake | S | |||||
| 4-wheel hydraulic brake + hand brake | O | ||||||
| 4-wheel hydraulic brake, front disc brake, rear drum brake | O | ||||||
| Accelerator | Stepless speed change | S | |||||
| Suspension system | Front and rear plate spring + cylinder hydraulic shock absorber | S | |||||
| Driving mode | Rear axle two stage deceleration, motor direct driving | S | |||||
| Rear axle | Integrated, Gear ratio 12.76:1 | S | |||||
| Integrated, Gear ratio 10.26:1 | O | ||||||
| Wheel & Tyre | 10x6 Alumimum wheel & 205/50-10 4PR | S | |||||
| 6J-10 steel wheel with cap & 205/50-10 4PR | O | ||||||
| 8*7 steel wheel with cap & 18*8.5-8 4PR | O | ||||||
Warranty!
13 months warranty to our electric vehicles from the shipping date
