Chinese Model Mini Truck for Park , 1000kgs Loading Capacity, CE Approved
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Capacity (Load):
1 - 10t
Drive Wheel:
4x2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Flat Cargo Truck of Electric Industrial Car With 800kgs Loading Capacity, CE ApprovedNegotiableMOQ: 1 Unit -
Electric Industrial Utility Vehicle With Scissor Lifter , CE ApprovedNegotiableMOQ: 1 Unit
-
Electric Industrial Utility Vehicle, 1500kgs Loading Capacity, CE ApprovedNegotiableMOQ: 1 Unit
-
Electric Fire Fighting Car With Outfire Equipments, CE ApprovedNegotiableMOQ: 1 Unit
-
Special Truck of Electric Fire Engine , CE ApprovedNegotiableMOQ: 1 Unit
Condition
New
Capacity (Load)
1 - 10t
Drive Wheel
4x2
Horsepower
Other, < 150hp
Transmission Type
Manual
Place of Origin
Jiangsu, China
Brand Name
Eagle
Model Number
EG6022H01
Chinese model mini truck for park , 1000kgs loading capacity, CE approved
Product Description
| Model | EG6022H | EG6022H01 | EG6022H04 | EG6022H05 |
| Description | 1.0T electric truck | 1.0T electric truck | 1.0T electric truck | 1.0T electric truck |
| System | 72V/5KW Series | 72V/5KW Series | 72V/7.5KW AC system | 72V/7.5KW AC system |
| Key Components | ||||
| Battery | 12xT105(185Ah@5hr rate) | 12xT105(185Ah@5hr rate) | 12xT105(185Ah@5hr rate) | 12xT105(185Ah@5hr rate) |
| Motor | 5KW Chinese motor | 5KW Chinese motor | 7.5KW Chinese motor | 7.5KW Chinese motor |
| Controller | Curtis 1205 (400A@1minute) | Curtis 1209(400A@2minutes) | Zapi AC2(400A@2minutes) | Zapi AC2(400A@2minutes) |
| Performance | ||||
| Passenger capacity | 2 | 2 | 2 | 2 |
| Range (loaded) based on flat road at a speed of 20km/h (km)* | >55 | >70 | >75 | >75 |
| Max. speed(km/h) | 45 | 55 | 55 | 30 |
| Minimum turning radius (m) | 5.3 | 5.3 | 5.3 | 5.3 |
| Max. climbing ability (loaded) | 20% | 20% | 20% | 12% |
| Max. movement after brake at speed of 20km/h | ≤NA | ≤NA | ≤NA | ≤NA |
| Max. loading weight | 1000kgs | 1000kgs | 1000kgs | 1000kgs |
| Net weight | 1623kgs | 1611kgs | 1586kgs | |
| Dimensions | ||||
| Overall dimensions (mm) | 4200X1500X2150 | |||
| Rear cargo bed dimension(mm) | 2600X1500X319 | |||
| Min. ground clearance (mm) | 150 | |||
| Wheelbase (mm) | 2370 | |||
| Front wheel tread (mm) | 1220 | |||
| Rear wheel tread (mm) | 1220 | |||
| Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration) | ||||
| Body and Frame | ||||
| Frame | Welded steel framework with sand blasting+paint treatment | |||
| Body | Fibreglass | |||
| Roof | Fibreglass | |||
| Rear Bumper | Steel Tube | |||
| Cabin | Aluminum frame + glass door | |||
| Windshield | Laminated glass | |||
| Seats | With backrest and headrest, sliding | |||
| Floor | Anti-sliding ruber floor mat | |||
| Battery sliding system | ||||
| Side rear view mirror | Two pieces per cart | |||
| Inner rear view mirror | One piece per cart in the middle of the windshield | |||
| Battery watering system,72V system | without water supply tool | |||
| Manual Pump | water supply tool (other water supply tools are available) | |||
| Seatbelt | 3-point, 2pcs | |||
| Electric system | ||||
| Lighting system and horn | 2 combined front lights(headlight, turning light, position light), 2 front foglight, 2 taillight(turn signals and brake lights), with DC-DC converter (converting from 48V to 12V), horn. | |||
| Dashboard | voltameter, ammeter, odometer, emergency switch; combined switch, meter indicator | |||
| Audio System | Radio and MP3 adaptor | |||
| Speaker | 2pcs | |||
| Reversing alarm | ||||
| Switch assembly | Lights switch, horn switch, wiper switch | |||
| Emergency power-off button | ||||
| Wiper | 12V, 50W, single arm | |||
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 72V, 25A | |||
| Offboard, Delta-Q 72V/12A 2pcs | ||||
| Heater | Diesel, for defrosting, 2KW | |||
| Amber Flashing light | On top | |||
| Steering and Suspension | ||||
| Steering system | Recirculating ball steering gear+ steering wheel | |||
| Electrical power steering system | ||||
| Brake system | Four wheel hydraulic drum brake+ parking brake | |||
| Brake assistant | ||||
| Transmission | Clutch, 4F+1R gear box, transmission shaft | Automatic drive system (stepless speed change) | ||
| Front suspension | plate spring + hydraulic shock absorber | |||
| Rear suspension | rear plate spring + hydrualic shock absorber | |||
| Rear axle | Integrated | |||
| Wheel & Tyre | 175R13C tubeless tire, 13*5.5 J steel rim | |||
Color
Packaging & Shipping
| Container loading qty | Assembled |
| Qty/20' | 1 |
| Qty/40' | 2 |
| Qty/40'HQ | 2 |
Company Information
Certifications
After-Sales Service
All electric golf carts sold by us are quality guaranteed.
We provide 13 months warranty to our electric vehicles from the shipping date.
