Help CenterShanghai PD220Y-1 220hp Top Quality Pengpu Brand Bulldozer
Related Products
-
160HP Shantui Bulldozer SD16 With Original Spare PartsUS$ 80,000 - 150,000MOQ: 1 Unit -
Brand New Bulldozer PD220Y-1 220hp Top Quality Pengpu CHINA Top BrandUS$ 80,000 - 100,000MOQ: 1 Unit
-
Top Exported Cheapest Price SHANTUI 160hp Crawler Bulldozer SD16US$ 60,000 - 90,000MOQ: 1 Unit
-
Best Price 220HP PENGPU Bulldozer PD220Y-1US$ 80,000 - 100,000MOQ: 1 Unit
-
PD220Y-1 New Arrival PENGPU Bulldozer for SaleUS$ 80,000 - 100,000MOQ: 1 Unit
Features of Hot Sale PENGPU Bulldozer PD220Y-1:
Shanghai-PD220Y-1 bulldozers are manufactured by Pengpu Machine Building Plant according to the imported technology of Komatsu D85A. It has outstanding advantages contrasting to relevant civil products:
1. Undercarriage steering hydraulic system
We imported, digested and applied the update steering valve of Komatsu, which lead to compact structure and easy operation.
2. Electronic monitor system
The 3-stage alarming & monitoring system is mounted in cabin, which can measure and monitor voltage, oil pressure, water temperature, oil temperature, engine speed. It also can monitor the status of fuel oil, cooling water and the condition of air filter. By the twinkling of light and buzzing of horn, the system can inform drivers the essential information of bulldozer and assure bulldozers working in normal, safe and high efficiency condition. There are also engine oil pressure gauge and water temperature gauge in the instrument panel to make parameters visible and own two-tier protection function.
3. Transmission, hydraulic parts, undercarriage and working equipment
Inter-changeable with same products of Komatsu as well as those products that are produced according to Komatsu technology.
4. The operating system is designed to be reasonable, handy and comfortable and allow more working place for the driver.
5. Final drive
The final drive gear is produced according to the imported technology strictly. Our imported specialized gear-processing equipment insure the high quality and the leading position in China.
6. The cabin is hexahedron with wide view scope.
Shanghai-PD220Y-1 bulldozer is the only one which import update technology of Komatsu D85A-21and occupy leading position in China.
NO |
DESCRIPTION |
UNIT |
SPECIFICATON |
|||
1 |
MODEL |
/ |
PD220Y-1 |
|||
2 |
Engine |
Model |
/ |
Chongqing Cummins NT855-C280S10 |
||
Type |
/ |
Straight vertical, four-stroke, water cooling, direct injection type. Turbocharger. |
||||
Number of cylinder-bore*stroke |
mm |
6-139.7*152.4 |
||||
Displacement |
l |
14 |
||||
Fly wheel/rated revolution |
kW/r/min |
162/1800 |
||||
Min. fuel consumption |
g/kw.h |
≤235 |
||||
3 |
Start method |
Type |
/ |
Electric starting motor |
||
Starting motor |
V/kW |
24V/11kW |
||||
Voltage/power | ||||||
Battery |
/ |
24V(12V*2)-195Ah |
||||
4 |
Lubrication system |
Lubrication type |
/ |
Forced lubrication. |
||
Cooling type |
/ |
Water cooling |
||||
7 |
Air filter type |
/ |
Dry type, precleaned cyclone air cleaner. |
|||
8 |
Transmission system |
Hydraulic torque converter |
/ |
3-element, single stage, single phase |
||
|
Transmission
|
/ |
Hand operated, hydraulic shift, planetary gear, multiple disc clutch, forced lubrication by gear pump. |
||||
Bevel gear |
/ |
Helical bevel gear, splash lubrication. |
||||
Steering clutch |
/ |
Wet, multiple disc, spring loaded, hand-operated with booster and hydraulic released. |
||||
Steering brake |
/ |
Wet, band brake, operated with hydraulic booster. |
||||
Final drive |
/ |
Spur gear, double reduction, splash lubrication. |
||||
9 |
Travel Speed |
Forward |
1st |
km/h |
0-3.6 |
|
2nd |
km/h |
0-6.5 |
||||
3rd |
km/h |
0-11.2 |
||||
Reverse |
1st |
km/h |
0-4.3 |
|||
2nd |
km/h |
0-7.7 |
||||
3rd |
km/h |
0-13.2 |
||||
10 |
Under carriage |
Suspension system |
/ |
Equalizer bar |
||
Track tension |
/ |
Hydraulic-adjusted |
||||
Sprocket |
pics |
Segmented |
||||
Number of track rollers (each side) |
pics |
6 (4 single, 2 double) |
||||
Number of carrier rollers (each side) |
pics |
2 |
||||
11 |
Track |
Type |
/ |
Sealed single grouser |
||
Track pitch |
mm |
216 |
||||
Number of track shoes |
pics |
38 |
||||
Track gauge |
mm |
2000 |
||||
Length of track on ground |
mm |
2730 |
||||
Track width |
mm |
560 |
||||
Ground pressure |
MPa |
0.078 |
||||
Ground clearance |
mm |
405 |
||||
12 |
Hydraulic system of work equipment |
Pump type |
/ |
CBT3160 gear pump |
||
Rated delivery |
L/min |
257 |
||||
Control valve |
/ |
Hand-operated, servo valve. |
||||
Working pressure |
MPa |
13.7 |
||||
Fuel tank |
L |
110 |
||||
Blade Max. lift above the ground |
mm |
1210 |
||||
Blade Max. drop below the ground |
mm |
540 |
||||
Max. lift speed |
m/s |
0.35 |
||||
Max. tilt |
mm |
735 |
||||
Pitch adjustment |
0 |
55 |
||||
13 |
blade |
type |
/ |
Straight tilt blade |
||
Dimension |
mm |
3725*1315 |
||||
Blade capacity |
m3 |
6.44 |
||||
15 |
Mix. Turning radius |
m |
3.3 |
|||
16 |
Ground ability |
0 |
30 |
|||
17 |
Dimension without ripper |
mm |
5750*3725*3575 |
|||
Dimension with ripper |
mm |
7530*3725*3575 |
||||
18 |
Operating weight without ripper |
kg |
24500 |
|||
Operating weight with ripper |
kg |
26800 |
||||
19 |
Three shank ripper |
mm |
|
|||
Max. dig below ground |
555 |
|||||
Max. lift above ground |
666 |
|||||
20 |
Single shank ripper |
mm |
|
|||
Max. dig below ground |
666 |
|||||
Max. lift above ground |
598.3 |
|||||
Sales Service
u Being available online 24 hours a day.
u Responding to your e-mails at the first time.
u Providing the best choice according to the customer’s needs.
u Giving reception and organize visit of the factory, meeting, technical communication for the customers.
After-sales Service
u Warranty: Silkway grants our clients a twelve-month-period or 2000-hours warranty for any machine purchased from us. During the warranty period, the defective parts will be repaired or replaced free of charge. But it does not cover all those parts damaged due to interventions for presumed problems or non conforming verification.
u Installation&Maintenance: Silkway has the ability to provide you with overall installation of complicated machinery and equipment, such as, crawler crane, tower crane, construction hoist, etc. Helping you to carry out the normal operation of the machines immediately.
01 WHAT ARE OUR ADVANTAGES COMPARED WITH ?
u Competitive Price - As a professional construction machinery exporter, we have abundant resources for pre-sale, sale and sale service. We work as the leading dealers of various leading China construction machinery manufacturers/factories, and are treated with best dealership price every year. From numerous comparison and feedbacks from clients, our price is more competitive than manufacturer /factories.
u Quick Response- Our team is consisted of diligent and enterprising people, working to respond client inquiries and questions all the time. Most problem can be solved within 12 hours.
02 WHICH TERMS OF PAYMENT CAN WE ACCEPT ?
u On T/T term, 30% down payment should be paid in advance, and 70% balance should be paid within 5 days before departure goods from factory.
u On L/C term, a 100% irrevocable L/C at sight by our acceptable bank.
03 HOW LONG WILL OUR PRICE BE VALID ?
We are a tender and friendly supplier, never greedy on windfall profit. Basically, our price remain s stable through the year. We only adjust our price based on two situations:
u The rate of USD /RMB varies significantly according to the international currency exchange rates.
u Manufacturers/factories adjusted to the machine price, because of the increasing of labor cost and raw material cost.
04 WHAT LOGISTICS WAYS WE CAN WORK FOR SHIPMENT?
We can ship construction machinery by various transportation tools.
u For 90% of our shipment, we will go by sea, for other machinery, like truck crane, big bulldozer and road roller, either by RO/RO and Bulk shipment.
u For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan, etc., we can ship construction machinery by road or railway.
u For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
05 HOW LONG IS OUR GUARANTEE TIME?
u 2000 working hours or one year from the date of B/L, which comes first.
u Engineers available to service machinery overseas.
Silkway is very famous construction machinery exporter in China and have exported products to more than 60 countries. Our main products are as follows: XCMG wheel loader, road roller, motor grader, excavator, truck crane and SHANTUI bulldozer etc. We always guarantee official products, quick after-sale service, and the most competitive price.
