5 Ton fast speed shaft driven diesel cable pulling winch
- Shanghai
- T/T Credit Card
You May Like
-
5 Ton High speed gasoline/petrol powered winch with HONDA/YAMAHA engine
-
Electric Power Source 2014 Best Portable 8 Ton Electric Winch For Sale
-
3 Ton Cable Pulling Wire Winch With Petrol Engine
-
8 Ton Portable Electric Crane Winch
-
3 Ton Gasoline Engine Wire Rope Winch
-
Three Ton Yamaha Petrol Powered Engine Winch
Product Details
| Place of Origin | Jiangsu, China | Brand Name | XINYA | |
| Model Number | JJM-5 | Power Source | Other, diesel | |
| Application | Cranes | Capacity | 50KN |
Product Description
5 Ton fast speed shaft driven diesel cable pulling winch
Application
5 Ton fast speed shaft driven diesel cable pulling winch is used for tower erection,pole setting,stringing wire in electrical power line construction.
Technical Data of 5 Ton fast speed shaft driven diesel cable pulling winch
| Model | Engine | Power | Gear: Forward | Pull Force(KN) | Speed(m/min) | Weight(Kg) | Dimension(mm) |
| JJM-5B | 186F Diesel Engine | 6.3KW, 3600rpm | SlowⅠ | 50 | 5 | 200 | 1200*600*750 |
| Slow Ⅱ | 30 | 9 | |||||
| Fast Ⅰ | 15 | 14 | |||||
| Fast Ⅱ | 9 | 24 |
Please tell us the following information in your enquiry:
1. Engine Power ?
2. Pulling Speed(m/min) ?
3. Pulling capacity?
we'll give you a good price after confirming the above info.
Welcome to contact us by phone or e-mail, if you are interesting in our products.
