Pulling Rope Galvanized Anti Twisting Braided Steel Wire Rope
Negotiable
MOQ: 500 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Steel Grade:
Galvanized steel wire rope
Standard:
BS, DIN, GB
Wire Gauge:
7-36mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hexagon Anti Twist Galvanized Stainless Steel Wire RopeUS$ 0.4 - 6MOQ: 500 Meters -
Anti Twist Galvanized Stainless Steel Wire RopeUS$ 0.4 - 6MOQ: 500 Meters
-
24mm Anti-twisting Breaking Load 360KN Braided Steel Wire Rope Overhead Line Stringing RopeUS$ 0.5 - 3MOQ: 500 Meters
-
High Strength Anti-twisting Braided Steel Wire Rope 11mm GalvanizedUS$ 0.5 - 3MOQ: 500 Meters
-
22mm 12 Strands 320kN Anti Twist Wire Rope Overhead for Transmission Line Stringing MachineUS$ 0.5 - 3MOQ: 500 Meters
Steel Grade
Galvanized steel wire rope
Standard
BS, DIN, GB
Wire Gauge
7-36mm
Place of Origin
Jiangsu, China
Type
Other, Galvanized, Galvanized Steel Wire Rope
Application
Construction
Alloy Or Not
Non-alloy
Special Use
Free Cutting Steel
Brand Name
XINYA
Pulling Rope Galvanized Anti Twisting Braided Steel Wire Rope
ISO9001:2008 certified.
CE approved.
Application
Applied to mechanical pulling and tensioning release conductors, unsuitable to pulling ropes for small diameter winch.
Features
Braided 1960 Mpa high-strength galvanized steel wire.
Notes:The specification and length of steel can custom according to your request.
Technical Data
| Order number | Structure | Diameter(mm) | Single bundle diameter(mm) | Breaking force(KN) | Production length(m) |
| 10763 |
Square eight strands |
7 | Φ2.0 | 34.38 | 1000 |
| 10764 | 9 | Φ2.5 | 53.90 | ||
| 10765 | 11 | Φ3.0 | 76.94 | ||
| 10766 | 13 | Φ3.5 | 105.04 | ||
| 10767 | 15 | Φ4.0 | 116.6 | ||
| 10768 |
Square twelve strands |
11 | Φ2.5 | 80.8 | |
| 10769 | 13 | Φ3.5 | 115.4 | ||
| 10770 | 15 | Φ3.5 | 157.55 | ||
| 10771 | 18 | Φ4.0 | 206.27 | 800 | |
| 10772 | 22 | Φ4.5 | 260.3 | ||
| 10773 |
Hexagon twelve strands |
11 | Φ2.5 | 80.8 | 1000 |
| 10774 | 13 | Φ3.0 | 115.4 | ||
| 10775 | 15 | Φ3.5 | 157.5 | ||
| 10776 | 18 | Φ4.0 | 205.71 | 800 | |
| 10777 | 20 | Φ5.0 | 260.34 | ||
| 10778 | 24 | Φ5.0 | 320.82 | ||
| 10779 |
Hexagon eighth strands |
21 | Φ3.0 | 173.1 | |
| 10780 | 24 | Φ3.5 | 236.33 | ||
| 10781 | 27 | Φ4.0 | 309.40 | 600 | |
| 10782 | 30 | Φ4.5 | 389.28 | ||
| 10783 | 33 | Φ5.0 | 471.22 | ||
| 10784 | 36 | Φ5.5 | 581.75 |
