China Top1 Manufacturer HELI New H3 Series with Japanese Engine 3.5 ton diesel forklift truck
| Characteristic | Unit | |||
| 1 | Manufacturer | HELI | HELI | |
| 2 | Model | CPC35-WS1H | CPCD35-WS1H | |
| 3 | Load Capacity | kg | 3500 | 3500 |
| 4 | Load center | mm | 500 | 500 |
| 5 | Power Type | DIESEL | DIESEL | |
| 6 | Operation mode | Seat-Type | Seat-Type | |
| Tire | ||||
| 7 | Front Tire | 28*9-15-14PR | 28*9-15-14PR | |
| 8 | Rear Tire | 6.50-10-10PR | 6.50-10-10PR | |
| Dimension Parameter | ||||
| 9 | Lifting height(standard) | mm | 3000 | 3000 |
| 10 | Mast Tilt(fwd/bwd) | deg | 6/12 | 6/12 |
| 11 | Min.Turning Radius | mm | 2420 | 2420 |
| 12 | Overall Length(with/without Forks) | mm | 3836/2766 | 3836/2766 |
| 13 | Overall Width | mm | 1225 | 1225 |
| 14 | Overall Height(Mast without activity) | mm | 2170 | 2170 |
| 15 | Wheel Base | mm | 1700 | 1700 |
| 16 | Tread(fwd/bwd) | mm | 1000/970 | 1000/970 |
| 17 | Overhang(fwd/bwd) | mm | 496/570 | 496/570 |
| 18 | Min.Under clearance(At the mast) | mm | 135 | 135 |
| 19 | Lateral Fork Adjustment(Outside of Forks) | mm | 250-1060 | 250-1060 |
| 20 | Fork Length | mm | 1070 | 1070 |
| 21 | Fork Width/Thickness | mm | 125/50 | 125/50 |
| Performance Parameter | ||||
| 22 | Lifting speed(Loaded) | mm/s | 400 | 400 |
| 23 | Lowing speed(Loaded) | mm/s | 350 | 350 |
| 24 | Traveling speed(Unloaded/Loaded) | km/h | 19/19 | 19/19 |
| 25 | Max.Gradeability(Loaded/Unloaded) | % | 15/20 | 21/20 |
| Weight | ||||
| 26 | Service weight | kg | 4800 | 4800 |
| Engine and Gearbox | ||||
| 27 | Engine Manufacturer/Model | Japanese Isuzu C240 | Japanese Isuzu C240 | |
| 28 | Engine rated power | Kw/rpm | 34.3/2500 | 34.3/2500 |
| 29 | Engine rated torque | Nm/rpm | 137.7/1800 | 137.7/1800 |
| 30 | Engine Cyliner number-borexstroke | 4-86*102 | 4-86*102 | |
| 31 | Engine Displancement | L | 2.369 | 2.369 |
| 32 | Emission | Euro Stage3A | Euro Stage3A | |
| 33 | Engine fuel tank capacity | L | 40 | 40 |
1.Well-Know Trademark Of China
2.First Brand of in Forklift Market in China
3.First Brand Of Indepent Innovation Forklift in China
4.AAA-Class Quality Service of China
5.Professional design team and work fast sales department of your service
6.Alibaba golden supplier,VIP trade assurance supplier
7.Ranking 8th in Forklift Manufacturing Industry in the World
HELI is authorized with the independent export rights,and over 90% of its products are exported directly by HELI.HELI has also established 76 forklift export agencies in the U.S.A,Germany,and the Netherlands.HELI' s efficient service network has been established to support HELI customers worldwide.The products of HELI have been exported to Europe,America,Australia and Southeast Asia,and sales have been completed in 130 countries.Among its exports,70% of the products are directed to Europe and America.The brand of HELI has already registered in more than 60 countries.
